描述
一、产品定位与核心优势
高端型号定位：
CP435T是CP400系列中的旗舰产品，在屏幕尺寸、通信接口、存储容量、计算性能上较同系列其他型号（如CP420B、CP415M）有显著提升，尤其适合多设备协同、大数据处理、实时视频监控、复杂逻辑控制的场景（如汽车总装线、智能电网调度中心、化工联合装置控制室）。
与CP420B相比，CP435T的处理器性能更强（四核处理器），存储容量更大（4GB RAM+8GB Flash），且支持更多冗余协议（如HSR/PRP），可承载更复杂的工程组态、数据分析、机器学习模型推理等任务。
核心价值：
提升系统集成效率：通过多协议兼容性，直接连接PLC、变频器、传感器、智能电表、摄像头等设备，减少网关数量，降低系统复杂度和成本。
增强操作体验：21.5英寸Full HD触摸屏+电容式多点触控，支持手势操作（缩放、滑动、旋转），提升操作便捷性和数据可视化效果。
保障系统可靠性：工业级硬件设计（宽温、抗干扰、冗余电源）+网络安全防护，确保7×24小时稳定运行，满足关键基础设施的严苛要求。
二、核心功能与特性
1.高性能显示与交互
屏幕参数：
尺寸：21.5英寸TFT LCD显示屏，支持横屏/竖屏安装，适应控制台、监控中心、操作台等不同场景。
分辨率：1920×1080像素（Full HD），显示清晰细腻，可同时展示多组数据、趋势图、报警信息、视频流（如摄像头画面）。
亮度：600 cd/m²（典型值），支持自动调光，适应强光（户外）或暗光（地下）环境。
触摸屏：电容式多点触控（支持10点触控），响应时间<8ms，支持湿手操作（IP69K防护等级可选），适用于食品加工、制药等潮湿环境。
界面设计：
预装软件：基于ABB Automation Builder或CodeSys开发的HMI工程软件，支持图形化组态，可快速创建动态画面、按钮、仪表盘、3D模型、视频监控界面。
多语言支持：内置30+种语言库（包括中文、英文、德文、日文等），支持语言切换热键，方便国际化项目部署。
自定义主题：支持品牌色、字体、图标自定义，匹配企业VI规范，提升品牌形象。
2.多协议工业通信支持
内置通信接口：
以太网端口：2×10/100/1000Mbps RJ45端口，支持并行冗余协议（PRP）和高速冗余协议（HSR），实现零切换时间（<5μs）的网络冗余，适用于关键控制回路（如轨道交通信号系统、核电站安全级DCS）。
串口：2×RS485/RS232端口（可选），支持Modbus RTU、Profibus DP、CANopen等协议，兼容legacy设备。
USB接口：2×USB 3.0端口（Type A）+1×USB 2.0端口（Type C），用于固件升级、数据导出、外设连接（如键盘、鼠标、U盘、摄像头）。
扩展槽：1×Mini PCIe插槽+1×M.2插槽，可插入4G/5G模块、Wi-Fi 6模块、SSD固态硬盘，实现无线通信或本地数据存储加速。
协议兼容性：
PLC协议：支持ABB AC500、AC800M、AC800F系列PLC，以及西门子S7-1200/1500、罗克韦尔ControlLogix、三菱FX/Q系列、欧姆龙NJ/NX系列等第三方PLC（通过OPC UA或Modbus TCP）。
工业以太网协议：Profinet IO（控制器/设备）、EtherNet/IP（Scanner/Adapter）、Modbus TCP（主/从站）、OPC UA Server/Client、BACnet/IP（楼宇自动化）、DNP3（电力自动化）、IEC 61850（变电站自动化）、MQTT（物联网）。
数据采集协议：支持IEC 60870-5-104（电力调度）、SQL（数据库连接）、ODBC（数据源访问），可直接连接智能电表、RTU设备、IED装置、云平台。
1.Product positioning and core advantages
High-end model positioning:
CP435T is a flagship product in the CP400 series.It has significantly improved screen size,communication interface,storage capacity,and computing performance compared with other models in the same series(such as CP420B and CP415M).It is especially suitable for scenarios such as multi-device collaboration,big data processing,real-time video surveillance,and complex logic control(such as automotive assembly line,smart grid dispatching center,and chemical joint device control room).
Compared with the CP420B,the CP435T has stronger processor performance(quad-core processor),larger storage capacity(4GB RAM+8GB Flash),and supports more redundant protocols(such as HSR/PRP),which can carry more complex engineering configuration,data analysis,machine learning model inference and other tasks.
Core Values:
Improve system integration efficiency:Through multi-protocol compatibility,directly connect PLC,frequency converter,sensor,smart meter,camera and other equipment to reduce the number of gateways and reduce system complexity and cost.
Enhanced operation experience:21.5-inch Full HD touch screen+capacitive multi-touch,supports gesture operation(zoom,slide,rotate),improving operational ease and data visualization.
Ensure system reliability:industrial-grade hardware design(wide temperature,anti-interference,redundant power supply)+network security protection to ensure stable operation in 7×24 hours and meet the strict requirements of critical infrastructure.
2.Core functions and characteristics
1.High-performance display and interaction
Screen parameters:
Size:21.5-inch TFT LCD display,supports horizontal screen/vertical screen installation,adapting to different scenarios such as console,monitoring center,and operating table.
Resolution:1920×1080 pixels(Full HD),the display is clear and delicate,and can display multiple sets of data,trend charts,alarm information,and video streams(such as camera screens)at the same time.
Brightness:600 cd/m²(typical),supports automatic dimming,adapting to strong(outdoor)or dark(underground)environments.
Touch screen:Capacitive multi-touch(supports 10-touch),response time<8ms,support wet hand operation(IP69K protection level is optional),suitable for humid environments such as food processing and pharmaceuticals.
Interface design:
Preinstalled software:HMI engineering software developed based on ABB Automation Builder or CodeSys,supports graphical configuration,and can quickly create dynamic pictures,buttons,dashboards,3D models,and video surveillance interfaces.
Multilingual support:Built-in 30+language libraries(including Chinese,English,German,Japanese,etc.),supports language switching hotkeys,which facilitates international project deployment.
Custom theme:Support brand colors,fonts,icons to customize,match corporate VI specifications,and enhance brand image.
2.Multi-protocol industrial communication support
Built-in communication interface:
Ethernet port:2×10/100/1000Mbps RJ45 port,supports parallel redundancy protocol(PRP)and high-speed redundancy protocol(HSR),achieving network redundancy with zero switching time(<5μs),suitable for critical control loops(such as rail transit signal systems,nuclear power plant safety-level DCS).
Serial port:2×RS485/RS232 port(optional),supports Modbus RTU,Profibus DP,CANopen and other protocols,and is compatible with legacy devices.
USB port:2×USB 3.0 port(Type A)+1×USB 2.0 port(Type C),used for firmware upgrade,data export,peripheral connection(such as keyboard,mouse,USB disk,camera).
Expansion slot:1×Mini PCIe slot+1×M.2 slot,which can be plugged into 4G/5G modules,Wi-Fi 6 modules,SSD solid-state drives,enabling wireless communication or local data storage acceleration.
Protocol Compatibility:
PLC protocol:Supports ABB AC500,AC800M,AC800F series PLCs,as well as third-party PLCs such as Siemens S7-1200/1500,Rockwell ControlLogix,Mitsubishi FX/Q series,Omron NJ/NX series,etc.(via OPC UA or Modbus TCP).
Industrial Ethernet protocols:Profinet IO(controller/device),EtherNet/IP(Scanner/Adapter),Modbus TCP(master/slave),OPC UA Server/Client,BACnet/IP(building automation),DNP3(power automation),IEC 61850(substation automation),MQTT(Internet of Things).
Data acquisition protocol:supports IEC 60870-5-104(power scheduling),SQL(database connection),ODBC(data source access),and can directly connect to smart meters,RTU devices,IED devices,and cloud platforms.
