描述
ABB CP450-T-ETH是一款人机界面（HMI）控制面板，带有10.4英寸TFT液晶显示屏，主要用于工业自动化领域，可与PLC、DCS系统连接。具体详情如下：
通信接口：具备以太网接口，通信速率为10/100Mbps。此外，还设有COM1（9针母连接器，支持RS232或RS485）、COM2（25针母连接器，支持RS232、RS422或RS485）、COM3（9针母连接器，支持RS422或RS485）等通信端口。
电源参数：供电电压为24V DC，最大功耗4.8W。
尺寸重量：尺寸约为45mm×100mm×115mm，重量约0.25kg。
工作环境：工作温度范围为-20℃至+60℃，存储温度范围为-40℃至+85℃，湿度为5%至95%（无凝露）。
屏幕特性：采用TFT触摸屏，可显示64K色，具有高分辨率，能清晰显示图像和文本。触摸屏符合IP65/NEMA4的防水和防尘标准。
功能特点：拥有七个定义键（F1-F7）和一个菜单键，功能键可在CP400Soft中定义，用作设置ON/OFF值、更改屏幕等操作的“快捷键”。具备报警管理、配方管理、趋势查看、宏指令和梯形图等功能，还可进行数据记录和历史记录。
The ABB CP450-T-ETH is a human-machine interface(HMI)control panel with a 10.4-inch TFT LCD display.It is primarily designed for industrial automation and can be connected to PLC and DCS systems.Specific details are as follows:
Communication Interface:It features an Ethernet interface with a communication rate of 10/100 Mbps.It also has COM1(9-pin female connector,supporting RS232 or RS485),COM2(25-pin female connector,supporting RS232,RS422,or RS485),and COM3(9-pin female connector,supporting RS422 or RS485).
Power Supply:24V DC,maximum power consumption 4.8W.
Dimensions and Weight:Approximately 45mm×100mm×115mm,weighing approximately 0.25kg.Operating Environment:Operating temperature range:-20°C to+60°C,storage temperature range:-40°C to+85°C,humidity:5%to 95%(non-condensing).
Screen Features:TFT touch screen with 64K color display and high resolution for clear images and text.The touch screen meets IP65/NEMA 4 standards for water and dust resistance.
Functional Features:It features seven configurable keys(F1-F7)and a menu key.Function keys can be defined in CP400Soft and used as shortcut keys for operations such as setting on/off values and changing screens.It also provides functions such as alarm management,recipe management,trend viewing,macros,and ladder diagrams,as well as data logging and historical records.
