描述
ABB CP450T 1SBP260188R1001是一款工业控制触摸屏。以下是其产品详情：
基本信息
品牌：ABB
型号：CP450T
产品编号：1SBP260188R1001
类型：控制面板
产地：瑞典
尺寸：宽度297mm，高度222mm，深度52mm
重量：1.9kg
技术参数
电源供应：24V DC
功耗：30VA
工作温度：0-50℃
存储温度：-10-60℃
通信接口：RS-232/RS-485（3个端口），2个USB 2.0主机端口，1个USB 2.0设备端口
屏幕规格：10.4英寸TFT触摸屏，64K色
存储容量：512KB用户数据，8000KB用户程序
防护等级：IP20
认证：CE、CUL、RoHS
功能特点
操作便捷：配备10.4英寸TFT触摸屏，提供清晰直观的显示界面，还有7个可自定义功能键，可根据用户需求定制按键功能。
通信多样：支持多种通信协议，如Modbus RTU、Modbus ASCII等，方便与其他设备进行数据传输和通信。
安全可靠：具有9个用户级别的密码保护功能，确保系统安全。采用工业级组件，适合在恶劣环境下使用，具备高可靠性。
功能丰富：支持报警管理、配方管理、趋势显示、宏功能和梯形逻辑、子屏幕等软件功能，方便用户对系统进行监控和管理。
ABB CP450T 1SBP260188R1001 is an industrial control touch screen.The following are product details:
Basic Information
Brand:ABB
Model:CP450T
Product Number:1SBP260188R1001
Type:Control Panel
Origin:Sweden
Dimensions:Width 297mm,Height 222mm,Depth 52mm
Weight:1.9kg
Technical Parameters
Power Supply:24V DC
Power Consumption:30VA
Operating Temperature:0-50°C
Storage Temperature:-10-60°C
Communication Interfaces:RS-232/RS-485(3 ports),2 USB 2.0 host ports,1 USB 2.0 device port
Screen Size:10.4-inch TFT touchscreen,64K colors
Memory Capacity:512KB user data,8000KB user program
Protection Rating:IP20
Certifications:CE,CUL,RoHS
Features
Easy Operation:Equipped with a 10.4-inch TFT touchscreen,providing a clear and intuitive display interface,and 7 Customizable function keys allow you to customize key functions based on your needs.
Diverse Communications:Supports multiple communication protocols,such as Modbus RTU and Modbus ASCII,facilitating data transmission and communication with other devices.
Secure and Reliable:Nine user-level password protection ensures system security.Industrial-grade components ensure high reliability in harsh environments.
Feature-Rich:Supports alarm management,recipe management,trend display,macros,ladder logic,sub-screens,and other software features,enabling convenient system monitoring and management.
