描述
ABB CS513 3BSE000435R1是一款IEEE 802.3 LAN模块，主要用于工业自动化控制系统中的网络通信连接。以下是其产品详情：
基本信息
品牌：ABB
型号：CS513 3BSE000435R1
产地：瑞典
产品类型：通信模块
技术参数
数据传输速率：支持10/100Mbps自适应，部分资料显示可高达1Gbps。
通信接口：以太网接口，RJ45连接器。
通信协议：支持IEEE 802.3协议，还可支持PROFINET、EtherCAT、DeviceNet、Modbus等多种工业通信协议。
电源供应：5VDC或24VDC。
工作温度范围：-20℃至+70℃或-40℃至+85℃。
存储温度范围：-40℃至+85℃。
尺寸：约108mm×18mm×234mm或120mm×100mm×30mm等。
重量：约0.2kg或0.5kg。
功能特点
兼容性强：可与ABB的AC 800M控制器等多种设备配合使用，兼容ABB Advant OCS和S100 I/O系统，还支持Masterbus 300/300E协议，能在主CPU和从CPU模式下运行。
数据传输高效：支持高速数据传输，可满足工业自动化实时数据交换的需求。
诊断功能：可通过LED指示灯等提供诊断信息，方便故障排除，缩短维护时间。
安装方便：采用导轨安装方式，方便安装在标准DIN导轨上，节省空间，易于维护。
应用领域
广泛应用于电力、石油化工、冶金、制造业、水处理、建材等工业领域，可用于过程控制、SCADA系统、网络设备连接等场景。
The ABB CS513 3BSE000435R1 is an IEEE 802.3 LAN module primarily used for network communication in industrial automation control systems.Below are its product details:
Basic Information
Brand:ABB
Model:CS513 3BSE000435R1
Origin:Sweden
Product Type:Communication Module
Technical Parameters
Data Transfer Rate:Supports 10/100Mbps auto-sensing,with some datasheets indicating up to 1Gbps.
Communication Interface:Ethernet interface,RJ45 connector.
Communication Protocol:Supports IEEE 802.3,as well as various other industrial communication protocols such as PROFINET,EtherCAT,DeviceNet,and Modbus.
Power Supply:5VDC or 24VDC.
Operating Temperature Range:-20°C to+70°C or-40°C to+85°C.
Storage Temperature Range:-40°C to+85°C.Dimensions:Approximately 108mm×18mm×234mm or 120mm×100mm×30mm.
Weight:Approximately 0.2kg or 0.5kg.
Features
Compatible with a variety of devices,including ABB’s AC 800M controllers,and compatible with ABB Advant OCS and S100 I/O systems.It also supports the Masterbus 300/300E protocol and can operate in both master and slave CPU modes.
Efficient Data Transmission:Supports high-speed data transmission,meeting the real-time data exchange requirements of industrial automation.
Diagnostic Features:LED indicators provide diagnostic information,facilitating troubleshooting and reducing maintenance time.
Easy Installation:Mounts easily on standard DIN rails,saving space and facilitating maintenance.
Applications:Widely used in industries such as power,petrochemicals,metallurgy,manufacturing,water treatment,and building materials,it can be used for process control,SCADA systems,and network device connectivity.
