描述
ABB CT302A GJR2167200R0001是一款输出模块。以下是其产品详情：
基本信息
品牌：ABB
结构形式：模块式
安装方式：现场安装
产地：瑞典
重量：2.5KG
技术参数
通道数量：每个模块有8个输出通道，分为1组。
输出电压：信号1的输出电压为UP3（-0.8V），通常UP3为24V DC。
输出电流：每个通道的额定电流为500mA（UP3=24V时），所有通道的最大电流为4A。
漏电流：信号0时的漏电流小于0.5mA。
过载保护：具备短路和过载保护功能，当电流大于0.7A时，约100ms后会发出过载消息，短路/过载后会自动重新激活。
输出切换频率：阻性负载时可按需定制，感性负载时最大为0.5Hz，灯负载时最大为11Hz（最大功率5W）。
连接方式
使用可移除的9针和11针端子块进行连接，这些端子块的连接系统（弹簧端子或螺丝端子，从正面或侧面安装电缆）不同，且端子块不包含在模块的供货范围内，必须单独订购。
应用领域
广泛应用于数控机械、冶金、石油天然气、石油化工、化工、造纸印刷、纺织印染、机械、电子制造、塑料机械、电力、水利、水处理/环保、市政工程、锅炉供暖、能源、输配电等领域。
The ABB CT302A GJR2167200R0001 is an output module.The following are its product details:
Basic Information
Brand:ABB
Structure:Modular
Installation Method:On-site Installation
Origin:Sweden
Weight:2.5 kg
Technical Parameters
Number of Channels:Each module has 8 output channels,organized into 1 group.
Output Voltage:The output voltage for signal 1 is UP3(-0.8 V),typically 24 V DC.
Output Current:The rated current for each channel is 500 mA(at UP3=24 V),with a maximum current of 4 A for all channels.
Leakage Current:The leakage current for signal 0 is less than 0.5 mA.
Overload Protection:Short-circuit and overload protection are provided.When the current exceeds 0.7 A,an overload message is issued after approximately 100 ms.It automatically reactivates after a short circuit/overload.
Output switching frequency:Customizable for resistive loads,maximum 0.5Hz for inductive loads,and maximum 11Hz for lamp loads(maximum power 5W).
Connection Method
Connection is via removable 9-pin and 11-pin terminal blocks.These terminal blocks have different connection systems(spring terminals or screw terminals,front or side cable installation).The terminal blocks are not included in the module’s scope of supply and must be ordered separately.
Applications
Widely used in CNC machinery,metallurgy,oil and gas,petrochemicals,chemicals,paper and printing,textile printing and dyeing,machinery,electronics manufacturing,plastics machinery,electric power,water conservancy,water treatment/environmental protection,municipal engineering,boiler heating,energy,and power transmission and distribution.
