描述
ABB D0810 3BSE008510R1是一款数字量输出模块，属于ABB 800xa控制系统。以下是其产品详情：
基本信息
品牌：ABB
型号：D0810
产品代码：3BSE008510R1
产品类型：数字输出模块
产地：瑞典
电气特性
电源电压：额定值为24V DC，公差为±10%。
功率消耗：通常小于3W。
输出通道：16个数字输出通道。
输出类型：可根据配置选择继电器或晶体管输出。
电流额定值：每通道最大输出电流为0.5A，所有通道组合的总电流为8A。
信号特性：输出高电平≥15V DC，输出低电平≤5V DC，开关频率高达10Hz。
物理参数
尺寸：宽度45mm，深度102mm（包括连接器为111mm），高度119mm。
重量：约0.18kg。
安装方式：设计用于DIN导轨安装。
工作环境
工作温度范围：0℃至+55℃（垂直安装在紧凑型MTU中为+5℃至+55℃）。
存储温度范围：-40℃至+70℃。
相对湿度：5%至95%，非冷凝。
防护等级：IP20。
认证：符合CE、UL等标准，具备RoHS和WEEE合规性。
The ABB D0810 3BSE008510R1 is a digital output module for the ABB 800xa control system.The following are product details:
Basic Information
Brand:ABB
Model:D0810
Product Code:3BSE008510R1
Product Type:Digital Output Module
Origin:Sweden
Electrical Characteristics
Power Supply Voltage:Rated at 24V DC with a tolerance of±10%.
Power Consumption:Typically less than 3W.
Output Channels:16 digital output channels.
Output Type:Relay or transistor outputs are selectable depending on configuration.
Current Rating:Maximum output current per channel is 0.5A,with a total current of 8A for all channels combined.
Signal Characteristics:Output High Level≥15V DC,Output Low Level≤5V DC,with a switching frequency of up to 10Hz.
Physical Parameters
Dimensions:Width 45mm,Depth 102mm(111mm including connector),Height 119mm.Weight:Approximately 0.18 kg.
Mounting Method:Designed for DIN rail mounting.
Operating Environment
Operating Temperature Range:0°C to+55°C(+5°C to+55°C when mounted vertically in a compact MTU).
Storage Temperature Range:-40°C to+70°C.
Relative Humidity:5%to 95%,non-condensing.
Protection Rating:IP20.
Certifications:Compliant with CE,UL,and other standards,and RoHS and WEEE compliant.
