描述
ABB DATX100 3ASC25H208是一款脉冲变压器板，主要用于工业自动化控制系统中。以下是其产品详情：
基本信息
品牌：ABB
型号：DATX100 3ASC25H208
产品类型：脉冲变压器板
原产地：瑞士
技术参数
工作电压：24VDC
功耗：4.8W
输入信号范围：0-10VDC或4-20mA
输出信号范围：0-10VDC或4-20mA
通道数量：16个
频率响应：高达50kHz
电流额定值：最大10A
精度：±0.1%of span
绝缘等级：H级
工作温度范围：-25°C至+70°C
存储温度范围：-40°C至+85°C
湿度：10%至95%非凝结
尺寸：99mm（高）×22.5mm（宽）×114.5mm（深）
重量：约1.03kg
连接类型：标准DIN导轨安装
通信协议：RS-485（MODBUS RTU）、以太网（10/100Mbps）
功能特点
信号处理精准：能够将电流或电压信号转换为高精度脉冲信号，用于测量、控制和信号隔离，精度可达±0.1%of span。
可靠性高：内置黄金电容器，在电源中断时可维持存储器数据，确保事件列表和扰动记录器数据不丢失。全金属外壳散热设计配合冗余电源输入接口，有效抵御电压波动与电磁干扰。
配置灵活：软件可调的滤波响应（0-1024ms）可适应不同工业环境下的信号稳定性需求，具备欠量程、超量程、高报警和低报警检测功能，支持开路输出设置。
兼容性强：支持MODBUS RTU、Profinet等多种工业通信协议，可轻松对接不同厂商的现场设备。
应用领域
电力系统：可作为中间总线与变电站监控系统的接口，负责数字化测量变量和逻辑信号的传输，支持过流保护、故障定位等功能。
工业过程控制：适用于化工反应釜的压力监测、炼油厂的流量控制等高精度信号处理场景。
智能建筑与能源管理：在智能楼宇中，可作为中央控制器连接空调、照明、安防等设备，通过RS485通信实现集中管理和能源优化。
船舶自动化：在船舶动力系统中，与ABB AC800M控制器配合，实现发动机状态监控、燃油消耗优化和船舶导航系统的实时数据交互。
ABB DATX100 3ASC25H208 is a pulse transformer board,mainly used in industrial automation control systems.Below are the product details:
Basic Information
Brand:ABB
Model:DATX100 3ASC25H208
Product Type:Pulse Transformer Board
Origin:Switzerland
Technical Parameters
Operating Voltage:24VDC
Power Consumption:4.8W
Input Signal Range:0-10VDC or 4-20mA
Output Signal Range:0-10VDC or 4-20mA
Number of Channels:16
Frequency Response:Up to 50kHz
Current Rating:Maximum 10A
Accuracy:±0.1%of span
Insulation Class:Class H
Operating Temperature Range:-25°C to+70°C
Storage Temperature Range:-40°C to+85°C
Humidity:10%to 95%non-condensing
Dimensions:99mm(H)×22.5mm(W)×114.5mm(D)
Weight:Approximately 1.03kg
Connection Type:Standard DIN Rail Mount
Communication Protocol:RS-485(MODBUS RTU),Ethernet(10/100Mbps)
Features
Precise Signal Processing:Converts current or voltage signals into high-precision pulse signals for measurement,control,and signal isolation,with an accuracy of up to±0.1%of span.
High Reliability:Built-in gold capacitors maintain memory data during power outages,ensuring event list and disturbance recorder data is not lost.The all-metal heat dissipation design and redundant power input ports effectively resist voltage fluctuations and electromagnetic interference.
Flexible Configuration:A software-adjustable filter response(0-1024ms)adapts to signal stability requirements in diverse industrial environments.Features include underrange,overrange,high alarm,and low alarm detection,and supports open-circuit output configuration.
Compatible:Supports multiple industrial communication protocols,including MODBUS RTU and Profinet,enabling easy integration with field devices from different manufacturers.
Applications
Power Systems:Serves as the interface between the intermediate bus and substation monitoring systems,transmitting digital measured variables and logic signals,and supporting functions such as overcurrent protection and fault location.Industrial process control:Suitable for high-precision signal processing scenarios such as pressure monitoring in chemical reactors and flow control in refineries.
Smart building and energy management:In smart buildings,it can serve as a central controller connecting air conditioning,lighting,security,and other equipment,enabling centralized management and energy optimization via RS485 communication.
Ship automation:In ship power systems,it works with ABB’s AC800M controller to enable engine status monitoring,fuel consumption optimization,and real-time data exchange with the ship’s navigation system.
