描述
ABB DATX130 3ASC25H214是一款应用于电力等工业领域的模块，以下是其产品详情：
基本信息
品牌：ABB
型号：DATX130
部件编号：3ASC25H214
尺寸：紧凑型6U VME标准尺寸，160mm×233mm
重量：约0.14kg
输入电压：24V DC（-20%~+25%波动容忍）
功耗：≤35W（典型）
处理器
TI TMS320C6748浮点DSP：主频456MHz，支持单精度/双精度浮点运算。
ARM Cortex-M3协处理器：负责I/O管理和通信中断处理，双核架构，主DSP负责控制算法，协处理器处理实时任务调度。
内存
256MB DDR2 SDRAM：用于程序运行和数据缓存。
128MB NAND Flash：存储固件和配置数据。
4MB EEPROM：保存关键参数，支持掉电保持。
通信接口
2×1000Base-T Ethernet：支持IEEE 1588v2精确时间协议，同步精度≤1μs。
1×RS-485串口：用于现场调试和设备维护。
1×CAN总线：连接本地I/O模块。
1×光纤接口：支持HDLC/IEC 61850-9-2LE协议，用于站间通信。
I/O扩展能力
模拟量：支持最多16个模拟量输入/输出通道，16位分辨率，采样率≥10kHz。
数字量：32个数字量输入/输出通道，支持24V DC信号，隔离电压≥2500V AC。
热电偶/热电阻：4路热电偶/热电阻输入，兼容J/K/T/E型热电偶和PT100/PT1000传感器。
功能特点
作为主处理单元：作为MACH2控制系统的主处理单元，负责执行实时控制算法、数据采集、逻辑运算和通信管理。
支持双冗余配置：可实现主备模式无缝切换，确保系统可用性≥99.999%，符合IEC 61850-90-5标准。
应用场景
高压直流输电：如换流阀触发控制、直流电压/电流调节、功率反转控制等。
柔性交流输电：包括静止同步补偿器、可控串联补偿控制、统一潮流控制器、动态电压恢复器核心计算等。
电网稳定控制：可用于频率/电压紧急控制、低频振荡抑制、广域测量系统数据融合与决策等。
The ABB DATX130 3ASC25H214 is a module for industrial applications such as power generation.Product details are as follows:
Basic Information
Brand:ABB
Model:DATX130
Part Number:3ASC25H214
Dimensions:Compact 6U VME standard size,160mm x 233mm
Weight:Approximately 0.14kg
Input Voltage:24V DC(-20%to+25%fluctuation tolerance)
Power Consumption:≤35W(typical)
Processor:TI TMS320C6748 floating-point DSP:456MHz clock speed,supporting single-precision and double-precision floating-point operations.
ARM Cortex-M3 coprocessor:Responsible for I/O management and communication interrupt handling.Dual-core architecture:The main DSP handles control algorithms,while the coprocessor handles real-time task scheduling.
Memory:256MB DDR2 SDRAM:For program execution and data caching.128MB NAND Flash:Stores firmware and configuration data.
4MB EEPROM:Stores key parameters and supports power-off retention.
Communication Interfaces
2 x 1000Base-T Ethernet:Supports IEEE 1588v2 Precision Time Protocol,with synchronization accuracy≤1μs.
1 x RS-485 serial port:For on-site commissioning and equipment maintenance.
1 x CAN bus:Connects local I/O modules.
1 x Fiber optic port:Supports HDLC/IEC 61850-9-2LE protocol for inter-station communication.
I/O Expansion Capabilities
Analog:Supports up to 16 analog input/output channels,16-bit resolution,and a sampling rate≥10kHz.
Digital:32 digital input/output channels,supporting 24V DC signals and an isolation voltage≥2500V AC.Thermocouple/RTR:Four thermocouple/RTR inputs,compatible with J/K/T/E type thermocouples and PT100/PT1000 sensors.
Features
Main Processing Unit:Serves as the main processing unit of the MACH2 control system,responsible for executing real-time control algorithms,data acquisition,logical operations,and communication management.
Dual Redundancy:Enables seamless switching between active and standby modes,ensuring system availability≥99.999%,in compliance with IEC 61850-90-5.
Application Scenarios
HVDC:Applications include converter valve triggering control,DC voltage/current regulation,and power reversal control.
Flexible AC Transmission:Applications include static synchronous compensator(SSC),controlled series compensation(CSCC),unified power flow controller(UPFC),and dynamic voltage restorer core computation.
Grid Stability Control:Applications include frequency/voltage emergency control,low-frequency oscillation suppression,and wide-area measurement system data fusion and decision-making.
