描述
ABB DC523 1SAP240500R0001是一款数字量输入输出模块，适用于ABB的S500 I/O系统。以下是其产品详情：
品牌：ABB
部件编号：1SAP240500R0001
产品类型：数字量输入输出模块
原产国：瑞典
通道配置：24个可配置通道，可设置为数字量输入（DI）或数字量输出（DO）。
电压范围：输入为0-30V DC，输出为24V DC，每个通道能够支持高达0.5A的电流。
辅助端子：配备4个0V端子和4个24V DC端子，便于电源连接。
响应时间：延迟时间可在0.1-32ms之间调节，可根据应用需求进行定制。
防护等级：IP20，适用于受保护的环境。
安装方式：设计为DIN导轨安装（TH 35-15），可轻松集成到控制面板中。
工作温度范围：0℃至+60℃。
存储温度范围：-40℃至+70℃。
电源电压：20.4-28.8V DC。
尺寸：宽67.5mm，高76mm，深62mm。
净重：0.115kg，毛重0.139kg。
The ABB DC523 1SAP240500R0001 is a digital input/output module for ABB’s S500 I/O system.Product details are as follows:
Brand:ABB
Part Number:1SAP240500R0001
Product Type:Digital Input/Output Module
Country of Origin:Sweden
Channel Configuration:24 configurable channels,which can be configured as digital inputs(DIs)or digital outputs(DOs).
Voltage Range:Inputs are 0-30V DC,outputs are 24V DC,and each channel can support up to 0.5A of current.
Auxiliary Terminals:Equipped with four 0V terminals and four 24V DC terminals for convenient power connection.
Response Time:The delay time is adjustable from 0.1 to 32ms and can be customized to meet application requirements.
Protection Rating:IP20,suitable for protected environments.Mounting:Designed for DIN rail mounting(TH 35-15),it can be easily integrated into a control panel.
Operating temperature range:0°C to+60°C.
Storage temperature range:-40°C to+70°C.
Supply voltage:20.4-28.8V DC.
Dimensions:Width 67.5mm,Height 76mm,Depth 62mm.
Net weight:0.115kg,Gross weight 0.139kg.
