描述
基本信息
产品ID：1SAP220500R0001
EAN：4016779649056
目录描述：接口模块，CS31从站，8路数字量输入（24VDC），16路可配置数字量输入/输出（24VDC 0.5A）
尺寸：62mm×76mm×67.5mm
产品净重量：0.12kg
技术参数
数字量输入通道：8路，输入电压为24VDC，输入电流为5mA。
可配置数字量输入/输出通道：16路，输出电压为24VDC，输出电流为0.5A，输出电压最大为28.8V。
信号延迟时间：0.1-32ms。
供电电压：20.4-28.8VDC。
防护等级：IP20。
工作温度范围：0°C至+60°C。
存储温度范围：-40°C至+70°C。
功能特点
通信接口：作为CS31从站接口模块，用于连接S500 I/O模块，实现控制系统与现场设备的信号交换。
可配置性：16个可配置的DI/DO通道，可根据应用需求灵活设置为输入或输出。
高速数据传输：支持Profibus-DP通信协议，通信速度最高可达12Mbps，能快速、稳定地在工业设备与控制系统之间传输数字信号。
状态指示：配备32个LED，用于显示操作和错误状态，方便用户进行调试和故障排查。
可扩展性：可通过连接多达7个额外的I/O模块进行扩展，满足不同规模的系统需求。
应用领域
广泛应用于电力、化工、制造业、造纸、印染等工业领域，可用于DCS控制系统、PLC可编程输送控制系统、智能消防供水控制系统等。
Basic Information
Product ID:1SAP220500R0001
EAN:4016779649056
Catalog Description:Interface module,CS31 slave,8 digital inputs(24VDC),16 configurable digital inputs/outputs(24VDC 0.5A)
Dimensions:62mm×76mm×67.5mm
Net Weight:0.12kg
Technical Parameters
Digital input channels:8,input voltage:24VDC,input current:5mA.
Configurable digital input/output channels:16,output voltage:24VDC,output current:0.5A,maximum output voltage:28.8V.
Signal delay:0.1-32ms.
Supply voltage:20.4-28.8VDC.
Protection level:IP20.Operating temperature range:0°C to+60°C.
Storage temperature range:-40°C to+70°C.
Features
Communication Interface:Serves as a CS31 slave interface module,connecting to S500 I/O modules to enable signal exchange between control systems and field devices.
Configurability:16 configurable DI/DO channels can be flexibly configured as inputs or outputs based on application requirements.
High-speed data transmission:Supports Profibus-DP communication protocol with speeds up to 12Mbps,enabling fast and stable transmission of digital signals between industrial equipment and control systems.
Status Indication:Equipped with 32 LEDs to display operating and error status,facilitating debugging and troubleshooting.
Scalability:Expandable by connecting up to 7 additional I/O modules to meet the needs of various system sizes.Applications:Widely used in industries such as power generation,chemical engineering,manufacturing,papermaking,and printing and dyeing,the system can be used in DCS control systems,PLC programmable conveying control systems,and intelligent fire water supply control systems.
