描述
ABB DI818是一款数字量输入模块，属于ABB S800 I/O系列，其产品详情如下：
部件编号：3BSE069052R1
输入通道数：32通道
输入电压范围：18-30VDC
输入电流：24VDC时为4.3mA
输入阻抗：5.6kΩ
隔离情况：分为两个独立隔离的组，每组16通道，与地隔离
电压监控：每组有一个电压监控输入，当电压消失时，过程电压监控输入会提供通道错误信号，该错误信号可通过模块总线读取
信号过滤：数字滤波时间可选，有2ms、4ms、8ms、16ms
尺寸：45mm×102mm×119mm
重量：约0.25kg
工作温度范围：0-55℃
存储温度范围：-40-70℃
防护等级：IP20
兼容性：可与MTU TU818、TU819、TU830配合使用
The ABB DI818 is a digital input module that belongs to the ABB S800 I/O series.Product details are as follows:
Part Number:3BSE069052R1
Number of Input Channels:32
Input Voltage Range:18-30 VDC
Input Current:4.3 mA at 24 VDC
Input Impedance:5.6 kΩ
Isolation:Two independently isolated groups of 16 channels each,isolated from ground
Voltage Monitoring:Each group has a voltage monitoring input.When the voltage drops out,the process voltage monitoring input provides a channel error signal,which can be read via the module bus.
Signal Filtering:Digital filter times are selectable:2ms,4ms,8ms,and 16ms.
Dimensions:45mm×102mm×119mm
Weight:Approximately 0.25 kg
Operating Temperature Range:0-55°C
Storage Temperature Range:-40-70°C
Protection Rating:IP20
Compatibility:Compatible with MTU TU818,TU819,TU830 for use with
