描述
ABB DO815 3BSE013258R1是一款用于S800 I/O系统的数字输出模块。以下是其产品详情：
基本信息
品牌：ABB
型号：DO815
产品编号：3BSE013258R1
原产国：瑞典
产品类型：数字输出模块
尺寸：45mm×119mm×102mm（宽×高×深），包括连接器为45mm×119mm×111mm
重量：约0.2kg
技术参数
输出通道：8通道
输出电压范围：10-30VDC
最大连续输出电流：2A（24VDC时）
输出类型：高边驱动器，限流型
隔离方式：输出分为两个独立隔离的组，每组4通道
保护功能：具备短路保护和过载保护功能
信号类型：直流24V
功耗：典型值4W
功能特点
隔离设计：两组通道相互隔离，提高了系统的抗干扰能力和安全性。
保护功能：短路保护可承受2.0A的短路电流，能有效保护模块和连接设备。
状态指示：通常模块上设有LED指示灯，可直观显示输出状态，便于监测和故障排查。
兼容性：可与TU810、TU812、TU814、TU830、TU833等模块终端单元配合使用。
The ABB DO815 3BSE013258R1 is a digital output module for the S800 I/O system.The following are product details:
Basic Information
Brand:ABB
Model:DO815
Product Number:3BSE013258R1
Country of Origin:Sweden
Product Type:Digital Output Module
Dimensions:45mm×119mm×102mm(W×H×D),45mm×119mm×111mm including connectors
Weight:Approximately 0.2kg
Technical Parameters
Output Channels:8
Output Voltage Range:10-30VDC
Maximum Continuous Output Current:2A(at 24VDC)
Output Type:High-Side Driver,Current-Limited
Isolation:Outputs are divided into two independently isolated groups,each with 4 channels
Protection:Provides short-circuit and overload protection
Signal Type:DC 24V
Power Consumption:Typical 4W
Features
Isolation Design:The two groups of channels are isolated from each other,improving system anti-interference capabilities and safety.Protection:Short-circuit protection can withstand a short-circuit current of 2.0A,effectively protecting the module and connected devices.
Status Indicator:LED indicators are typically provided on the module to visually display output status,facilitating monitoring and troubleshooting.
Compatibility:Compatible with module terminal units such as the TU810,TU812,TU814,TU830,and TU833.
