描述
ABB DO818 3BSE069053R1是一款用于S800 I/O系统的数字输出模块，以下是其产品详情：
基本信息
品牌：ABB
型号：DO818
产品编号：3BSE069053R1
原产国：瑞典
产品类型：数字输出模块
尺寸：45mm×119mm×102mm（宽×高×深）
重量：约0.245kg
技术参数
输出通道：32通道
输出电压范围：12-32VDC（标称24VDC）
最大连续输出电流：每通道0.5A
输出类型：高边驱动器
隔离情况：输出分为两个独立隔离的组，每组16通道，隔离电压50V
保护功能：具备短路、过压、过热保护功能
状态指示：每个输出通道都有输出状态指示LED
通信接口：可通过模块总线进行通信，用于读取输出状态和故障信息等
功能特点
多通道输出：32个输出通道可同时控制多个执行器，满足大规模控制需求。
隔离设计：两组通道相互隔离，提高了系统的抗干扰能力和安全性。
故障检测：每组都有电压监控输入，当电压消失时，会给出通道错误信号，错误信号可通过模块总线读取。
兼容性：可与TU818、TU819、TU830等模块终端单元配合使用。
The ABB DO818 3BSE069053R1 is a digital output module for the S800 I/O system.The following are its product details:
Basic Information
Brand:ABB
Model:DO818
Product Number:3BSE069053R1
Country of Origin:Sweden
Product Type:Digital Output Module
Dimensions:45mm×119mm×102mm(W×H×D)
Weight:Approximately 0.245kg
Technical Parameters
Output Channels:32
Output Voltage Range:12-32VDC(Nominal 24VDC)
Maximum Continuous Output Current:0.5A per channel
Output Type:High-Side Driver
Isolation:Outputs are divided into two independently isolated groups,each with 16 channels,and an isolation voltage of 50V.
Protection:Provides short-circuit,overvoltage,and overtemperature protection.
Status Indicator:Each output channel has an output status indicator.LED
Communication Interface:Communicates via the module bus for reading output status and fault information.
Features:
Multi-channel output:32 output channels can simultaneously control multiple actuators,meeting large-scale control needs.
Isolated Design:The two channels are isolated from each other,improving system anti-interference capabilities and safety.
Fault Detection:Each channel has a voltage monitoring input.When the voltage drops,a channel error signal is generated,which can be read via the module bus.
Compatibility:Compatible with module terminal units such as the TU818,TU819,and TU830.
