描述
ABB DSAI130D是一款模拟量输入模块，属于ABB Advant Master过程控制系统或S100 I/O系列模块。以下是其产品详情：
基本信息
品牌：ABB
型号：DSAI130D
产地：瑞典
产品类型：模拟量输入模块
技术参数
输入通道数：8个或16个。
输入信号类型：支持电压和电流输入，如±10V、±20mA、0-10V、4-20mA等。
分辨率：16位。
精度：±0.1%满量程。
转换时间：≤10ms。
采样速率：1kHz。
工作温度范围：-20℃至+60℃或-25°C至+70°C。
防护等级：IP20或IP65。
安装方式：DIN导轨安装。
功能特点
高精度测量：采用高精度A/D转换器，确保测量数据的准确性和可靠性。
可配置性强：可以通过软件配置模块参数，如输入类型、滤波时间等，适应不同的应用需求。
隔离设计：每个通道独立隔离，提高抗干扰能力，保障系统稳定运行。
模块化设计：易于安装和维护，支持热插拔，降低了维护成本和时间。
应用领域
过程工业：广泛应用于化工、冶金等行业的过程控制，用于采集温度、压力、流量等过程变量。
制造业：可用于生产线自动化、包装机械等，实现对生产过程的精确控制和监测。
楼宇自动化：适用于HVAC控制、照明控制等，采集温度、湿度等环境参数。
能源管理：在电力系统、石油和天然气行业中，用于能源数据的采集和管理。
The ABB DSAI130D is an analog input module,part of the ABB Advant Master process control system or S100 I/O series.The following are product details:
Basic Information
Brand:ABB
Model:DSAI130D
Origin:Sweden
Product Type:Analog Input Module
Technical Parameters
Number of Input Channels:8 or 16.
Input Signal Type:Supports voltage and current inputs,such as±10V,±20mA,0-10V,and 4-20mA.
Resolution:16-bit.
Accuracy:±0.1%of full scale.
Conversion Time:≤10ms.
Sampling Rate:1kHz.
Operating Temperature Range:-20°C to+60°C or-25°C to+70°C.
Protection Rating:IP20 or IP65.
Mounting Method:DIN rail.
Features
High-Precision Measurement:Utilizes a high-precision A/D converter to ensure accurate and reliable measurement data.
High Configurability:Module parameters,such as input type and filter time,can be configured through software to adapt to different application requirements.
Isolated Design:Each channel is independently isolated,improving interference immunity and ensuring stable system operation.
Modular Design:Easy to install and maintain,with hot-swappable functionality,reducing maintenance costs and time.
Applications
Process Industries:Widely used in process control in industries such as chemical and metallurgy,collecting process variables such as temperature,pressure,and flow.
Manufacturing:Suitable for production line automation and packaging machinery,enabling precise control and monitoring of production processes.
Building Automation:Suitable for HVAC control and lighting control,collecting environmental parameters such as temperature and humidity.
Energy Management:Used in power systems and the oil and gas industry for collecting and managing energy data.
