描述
ABB DSDP170 57160001-ADF是一款用于ABB Advant OCS和S100 I/O系统的脉冲计数板。以下是其产品详情：
基本信息
品牌：ABB
型号：DSDP170 57160001-ADF
通道数：32
产地：瑞典
技术参数
计数频率：最大50kHz
计数精度：±1个计数
输入电压范围：5VDC至24VDC
输入电流：最大10mA
功耗：<10W
工作温度范围：-20°C至+60°C
防护等级：IP67
功能特点
高精度计数：采用高精度计数技术，可准确测量和计数高速脉冲信号。
多种输入接口：支持推挽、漏极开路、源极开路等多种输入接口，方便与不同类型的传感器连接。
可编程设置：用户可通过编程设置模块的计数范围、计数方向、脉冲极性等参数，满足不同应用需求。
高速数据传输：支持高速数据传输，能将计数值和其他数据快速传输给控制系统或上位机软件处理。
应用领域
主要用于旋转编码器的计数、脉冲传感器信号的处理、生产线计数和监控、流量和速度测量、定位/长度和速度/频率测量等场景。.
The ABB DSDP170 57160001-ADF is a pulse counter board for ABB Advant OCS and S100 I/O systems.Product details are as follows:
Basic Information
Brand:ABB
Model:DSDP170 57160001-ADF
Number of Channels:32
Origin:Sweden
Technical Parameters
Counting Frequency:Maximum 50kHz
Counting Accuracy:±1 Count
Input Voltage Range:5VDC to 24VDC
Input Current:Maximum 10mA
Power Consumption:<10W
Operating Temperature Range:-20°C to+60°C
Protection Rating:IP67
Features
High-Precision Counting:Utilizes high-precision counting technology to accurately measure and count high-speed pulse signals.
Various Input Interfaces:Supports push-pull,open-drain,and open-source inputs,facilitating connection to various sensor types.Programmable Settings:Users can program the module’s counting range,counting direction,pulse polarity,and other parameters to meet diverse application requirements.
High-SpeedData Transfer:Supports high-speed data transmission,enabling rapid transmission of count valuesand other data to a control system or host software for processing.
Applications:Primarily used for rotary encoder counting,pulse sensor signal processing,production line counting and monitoring,flow and speed measurement,and positioning,length,speed,and frequency measurement.
