描述
ABB DSMB115是一款主控制板，以下是其产品详情：
基本信息
品牌：ABB
型号：DSMB115
原产国：瑞典
结构形式：模块式
安装方式：控制室安装
重量：约0.4千克
外形尺寸：25.4cm×5.1cm×25.4cm
产品特征
连接器：具有五个垂直电缆连接器，包括四个公连接器和一个母连接器；还有三个垂直接头连接器和三个卡入式连接器。
开关：有二十多个跳线开关，位于左上象限有一个复位开关。
指示灯：配备有指示灯。
其他组件：有一个电感线圈，用于检查电路板电压的TP测试点，超过五十五个集成电路，包括振荡芯片、现场可编程门阵列和用于数据存储的EPROM芯片，还有几个保险丝组件。此外，由两个辅助板填充，包括一块垂直安装的板和一个水平安装的板，均位于左下角。
技术参数
工作电压：220V
程序容量：16MB
LD指令处理器：硬PLC
I/O点数：2
功能：适用于同步电机的应用
产品认证：CE
The ABB DSMB115 is a main control board.The following are its product details:
Basic Information
Brand:ABB
Model:DSMB115
Country of Origin:Sweden
Construction Type:Modular
Installation Method:Control Room Installation
Weight:Approximately 0.4 kg
Dimensions:25.4 cm×5.1 cm×25.4 cm
Product Features
Connectors:Features five vertical cable connectors,including four male connectors and one female connector;three vertical header connectors,and three snap-on connectors.
Switches:Features over twenty jumper switches,including a reset switch in the upper left quadrant.
Indicator Lights:Features indicator lights.
Other Components:Features an inductor coil,TP test points for checking board voltages,over 55 integrated circuits,including an oscillator chip,a field-programmable gate array,and an EPROM chip for data storage,as well as several fuse assemblies.Additionally,the board is populated by two auxiliary boards:one vertically mounted and one horizontally mounted,both located in the lower left corner.Technical Parameters
Operating Voltage:220V
Program Capacity:16MB
LD Instruction Processor:Hard PLC
Number of I/O Points:2
Function:Suitable for synchronous motor applications
Product Certification:CE
ABB Model: GBU72 3BHE055094R0002 Model: 3BHE055094R0002 GBU72 Model: GBU72 Model: 3BHE055094R0002 Model: 3BHE031197R0001 Model: 3BHB030310R0001 Model: 73BHE055094R0002 GBU72 Model: 73BHE055094R0002 Model: GBU72 Model: ABB PCS6000 PRODUCT FAMLIY ABB 5SHY4045L0006 3BHB030310R0001 3BHE039203R0101 GVC736CE101
