ABB DSQC 1050 3HAC064474-001制动释放板产品详情
产品概述
ABB DSQC 1050是一款专用于ABB工业机器人的制动释放板（Brake Release Board）。该产品不是安装在控制器内部的板卡，而是一个独立的、手持式的诊断和维护工具，其主要功能是在机器人控制柜断电的情况下，手动释放机械臂各轴的制动器。
主要特性与规格
产品类型：手动制动释放工具
零件号：DSQC 1050，完整零件代码为3HAC064474-001
制造商：ABB
兼容系统：主要用于配备IRC5或新一代OmniCore控制器的ABB机器人。
功能：
手动操作：提供了针对机器人每个关节（通常为轴1至轴6）的独立按钮或开关，技术人员可以通过操作这些按钮来释放特定轴的制动器。
安全维护：允许在没有电源或发生故障时，手动移动机器人机械臂。这对于在安全区域内进行故障排除、位置恢复或常规维护操作至关重要。
物理和电气参数：
设计：通常是一个带有多个按钮和连接接口的紧凑型盒子，通过专用电缆连接到机器人控制柜内部的驱动模块。
电源：它不依赖于控制柜的主电源，通常使用内部电池或来自驱动模块的低功率供电。
ABB DSQC 1050 3HAC064474-001 Brake Release Board Product Details
Product Overview
The ABB DSQC 1050 is a brake release board specifically designed for ABB industrial robots.This product is not a controller-installed board;instead,it is a standalone,handheld diagnostic and maintenance tool.Its primary function is to manually release the brakes on each axis of the robot arm when the robot control cabinet is powered off.
Key Features and Specifications
Product Type:Manual Brake Release Tool
Part Number:DSQC 1050,full part code:3HAC064474-001
Manufacturer:ABB
Compatible Systems:Primarily for ABB robots equipped with IRC5 or next-generation OmniCore controllers.
Function:
Manual Operation:Provides individual buttons or switches for each joint of the robot(typically axes 1 through 6).Technicians can operate these buttons to release the brakes on specific axes.
Safe Maintenance:Allows manual movement of the robot arm in the event of a power outage or fault.This is crucial for troubleshooting,position recovery,or routine maintenance within a safe area.
Physical and Electrical Parameters:
Design:Typically a compact box with several buttons and connectors,connected to the drive module inside the robot control cabinet via a dedicated cable.
Power Supply:It is independent of the control cabinet’s main power supply and typically uses internal batteries or low-power power from the drive module.
