描述
ABB DSQC 211是一款电源供应板，以下是其产品详情：
基本信息
品牌：ABB
原产国：瑞典
产品类型：电源供应板
功能特点
电源输入：具备DC9-36V宽冗余双电源输入，典型DC24V，具有DC1500V电源隔离以及反接保护功能。
保护机制：提供电接口4000V的防雷，1.5A过流，600W浪涌保护，还配备电源故障继电器输出告警，继电器告警输出支持链路故障和电源故障告警输出，触点大容量为DC48V/1A。
通信接口：数据电接口采用9针的Sub_D插孔连接器，符合Profibus DP的协议规范，支持Profibus DP总线标准，通信速率包括9.6kBit/s、19.2kBit/s、45.45kBit/s、93.75kBit/s、187.5kBit/s、500kBit/s、1.5Mbit/s、6Mbit/s和12Mbit/s。
状态指示：配备6个双色LED状态指示灯，可直观显示电源板的工作状态。
安装方式：IP30防护等级，采用波浪纹铝制加强机壳，支持标准工业35mm导轨安装方式。
The ABB DSQC 211 is a power supply board.Product details are as follows:
Basic Information
Brand:ABB
Country of Origin:Sweden
Product Type:Power Supply Board
Features
Power Input:Features dual redundant DC9-36V power inputs,typically DC24V,with DC1500V power isolation and reverse polarity protection.
Protection Mechanism:Provides 4000V lightning protection,1.5A overcurrent,and 600W surge protection for the electrical interface.Also features a power failure relay output for alarms,supporting both link and power failures.The contact capacity is DC48V/1A.Communication Interface:The data interface utilizes a 9-pin Sub-D receptacle connector,compliant with the Profibus DP protocol and supporting the Profibus DP bus standard.Communication rates include 9.6kBit/s,19.2kBit/s,45.45kBit/s,93.75kBit/s,187.5kBit/s,500kBit/s,1.5Mbit/s,6Mbit/s,and 12Mbit/s.
Status Indicator:Six dual-color LED status indicators provide a visual display of the power board’s operating status.
Mounting:The unit boasts an IP30 protection rating and features a reinforced corrugated aluminum chassis that supports standard industrial 35mm rail mounting.
