描述
ABB DSQC 633A是一款串行测量板，主要用于ABB机器人系统中测量机器人末端执行器的位置和姿态。以下是其产品详情：
基本信息
型号：DSQC 633A
部件号：3HAC031851-001
品牌：ABB
尺寸：150mm×150mm×100mm
重量：约0.36kg
电源供应：12VDC，1.5A
技术规格
测量范围：±20mm
分辨率：0.1μm
精度：±0.5μm
重复性：±0.2μm
输出方式：模拟（0-10V）或数字（RS-232）
产品特点
高精度：具备高精度的测量性能，能为机器人的精准控制提供可靠数据支持。
兼容性强：可与其他ABB机器人系统无缝兼容，便于集成到机器人自动化生产线中。
诊断功能：模块提供多种诊断功能，可通过前面板的LED指示灯进行通道选择和诊断显示，8个绿色LED用于通道选择和诊断，另外8个绿色LED用于模拟值显示。
The ABB DSQC 633A is a serial measurement board primarily used to measure the position and posture of robot end-effectors in ABB robot systems.Product details are as follows:
Basic Information
Model:DSQC 633A
Part Number:3HAC031851-001
Brand:ABB
Dimensions:150mm×150mm×100mm
Weight:Approximately 0.36kg
Power Supply:12VDC,1.5A
Technical Specifications
Measuring Range:±20mm
Resolution:0.1μm
Accuracy:±0.5μm
Repeatability:±0.2μm
Output:Analog(0-10V)or Digital(RS-232)
Product Features
High Precision:Provides high-precision measurement performance,providing reliable data support for precise robot control.
Strong Compatibility:Seamlessly compatible with other ABB robot systems,facilitating integration into automated robotic production lines.Diagnostic function:The module provides a variety of diagnostic functions.Channel selection and diagnostic display can be performed through the LED indicators on the front panel.8 green LEDs are used for channel selection and diagnosis,and another 8 green LEDs are used for analog value display.
