描述
ABB DSQC116是一款数字量输出模块，主要用于工业自动化控制系统中。以下是其详细产品信息：
基本信息
品牌：ABB
型号：DSQC116
颜色：黑色
物料编码：685499
产地：美国
电气参数
输出通道：每个模块最多有24个晶体管输出通道。
电源电压：所有输出的公共电源电压通过端子1.8、2.8、3.8和4.8输入（过程电源电压正极，信号名称UP），通常为24V。
输出电压：信号1的输出电压为UP(-0.8 V)。
输出电流：每通道额定值为500mA（UP=24V时），所有通道一起的最大值为8A。
漏电流：信号0时漏电流小于0.5mA。
保护：具有短路保护和过载保护功能，UP上的额定保护熔断器为10A快速熔断器，过载消息（I>0.7 A）在约100ms后出现，短路/过载后可自动重新激活。
开关频率：阻性负载时根据要求而定，感性负载时最大0.5Hz，灯负载时最大11Hz（最大5W）。
电缆长度：屏蔽电缆最大1000m，非屏蔽电缆最大600m。
功能特点
通讯功能：具备通讯功能，可与其他设备进行数据传输，实现系统的自动化控制。
可编程控制：可进行编程，满足不同工业场景的控制需求。
适应多种环境：适用于燃气、供水、污水处理、冶金、钢铁制造、水力发电、火力发电、造纸行业、玻璃制造等多种工业领域。
The ABB DSQC116 is a digital output module primarily used in industrial automation control systems.Below is its detailed product information:
Basic Information
Brand:ABB
Model:DSQC116
Color:Black
Material Number:685499
Origin:USA
Electrical Parameters
Output Channels:Each module has up to 24 transistor output channels.
Supply Voltage:The common supply voltage for all outputs is input via terminals 1.8,2.8,3.8,and 4.8(process supply voltage positive,signal name UP),typically 24V.
Output Voltage:The output voltage for signal 1 is UP(-0.8V).
Output Current:Rated at 500mA per channel(at UP=24V),with a maximum of 8A for all channels combined.
Leakage Current:Less than 0.5mA for signal 0.Protection:Provides short-circuit and overload protection.The UP fuse is a 10A fast-blow fuse.An overload message(I>0.7 A)appears after approximately 100ms,and the device automatically reactivates after a short circuit/overload.
Switching Frequency:Variable for resistive loads,up to 0.5Hz for inductive loads,and up to 11Hz for lamp loads(up to 5W).
Cable Length:Up to 1000m for shielded cables,up to 600m for unshielded cables.
Features
Communication:Equipped with communication capabilities,it enables data transmission with other devices,enabling automated system control.
Programmable Control:Programmable to meet the control needs of various industrial scenarios.
Suitable for diverse environments:Suitable for a variety of industries,including gas,water supply,sewage treatment,metallurgy,steel manufacturing,hydropower generation,thermal power generation,papermaking,and glass manufacturing.
