描述
ABB DSQC266C是ABB工业机器人产品线中一款数字量输入/输出（I/O）模块，属于DSQC系列分布式I/O系统，主要用于机器人控制器与外部设备（如传感器、执行器、PLC等）之间的信号交互。以下是其详细信息整理：
产品概述
定位：DSQC266C是DSQC266系列的升级或变体型号（C可能代表版本更新或功能扩展），专为工业机器人自动化场景设计。
核心功能：提供高密度数字量I/O通道，支持DeviceNet通信协议，适用于需要实时控制和高可靠性的应用场景（如焊接、装配、搬运等）。
型号解析
DSQC：ABB机器人硬件模块的通用前缀，代表“Distributed Signal and Quality Control”（分布式信号与质量控制）。
266C：
266：可能表示基础型号（如DSQC266A的升级版）。
C：可能代表版本修订（如硬件改进、通信协议升级或功能扩展）。
核心特性
I/O配置
数字量输入（DI）：16通道，24V DC信号输入（支持源型/漏型接线，兼容常见传感器）。
数字量输出（DO）：16通道，24V DC晶体管输出（0.5A/通道，带短路保护，可直接驱动小型继电器或电磁阀）。
通信能力
DeviceNet接口：支持DeviceNet主站/从站模式，通信速率125Kbps至500Kbps，满足实时控制需求。
兼容性：可与ABB机器人控制器（如IRC5）及其他DeviceNet设备（如PLC、HMI）无缝集成。
工业级设计
防护等级：IP20（适用于控制柜内部安装）。
抗干扰：符合EMI/EMC标准，减少工厂环境中的电磁干扰。
工作温度：0°C至+55°C，适应恶劣工况。
The ABB DSQC266C is a digital input/output(I/O)module in ABB’s industrial robot product line.It belongs to the DSQC series distributed I/O system and is primarily used for signal exchange between robot controllers and external devices(such as sensors,actuators,and PLCs).The following is a summary of its details:
Product Overview
Positioning:The DSQC266C is an upgraded or variant model of the DSQC266 series(the”C”may represent a version upgrade or functional expansion),designed specifically for industrial robot automation scenarios.
Core Functions:It provides high-density digital I/O channels and supports the DeviceNet communication protocol,making it suitable for applications requiring real-time control and high reliability(such as welding,assembly,and handling).
Model Explanation
DSQC:A common prefix for ABB robot hardware modules,standing for”Distributed Signal and Quality Control.”
266C:
266:May indicate a base model(such as an upgraded version of the DSQC266A).C:May indicate a revision(e.g.,hardware improvements,communication protocol upgrades,or functional expansion).
Core Features
I/O Configuration
Digital Input(DI):16 channels,24V DC signal input(supports source/sink wiring,compatible with common sensors).
Digital Output(DO):16 channels,24V DC transistor output(0.5A/channel,short-circuit protected,capable of directly driving small relays or solenoid valves).
Communication Capabilities
DeviceNet Interface:Supports DeviceNet master/slave modes with communication rates of 125Kbps to 500Kbps,meeting real-time control requirements.
Compatibility:Seamlessly integrates with ABB robot controllers(e.g.,IRC5)and other DeviceNet devices(e.g.,PLCs and HMIs).
Industrial-Grade Design
Protection Rating:IP20(suitable for installation inside control cabinets).
Interference Immunity:Complies with EMI/EMC standards,reducing electromagnetic interference in factory environments.Operating temperature:0°C to+55°C,suitable for harsh working conditions.
