描述
核心功能
电源转换
将输入的交流电（AC 85-264V，频率47-63Hz）转换为控制器所需的稳定直流电（DC），确保电子系统（如控制器、电机、传感器等）的可靠运行。
保护与监测
过载保护：防止电流过大损坏设备。
过压/短路保护：避免电压异常或短路引发的故障。
热过载保护：通过温度监测防止模块过热。
故障反馈：提供清晰的视觉反馈（如指示灯）显示运行状态和故障条件。
高效稳定
转换效率>90%，减少能源损耗。
输出电流最高达10A，满足高负载需求。
技术参数
输入电压：85-264V AC（单相）
输出电流：最高10A
频率范围：47-63Hz
效率：>90%
工作温度：0°C至+55°C
存储温度：-25°C至+85°C
冷却方式：自然对流或风扇辅助散热
认证：CE、UL、RoHS
安装方式：控制器机箱内面板安装
尺寸与重量：约1000g（具体依型号而定）
Core Functions
Power Conversion
Converts input AC power(85-264V AC,47-63Hz frequency)into stable DC power required by the controller,ensuring reliable operation of electronic systems(such as controllers,motors,and sensors).
Protection and Monitoring
Overload Protection:Prevents damage to equipment due to excessive current.
Overvoltage/Short-Circuit Protection:Prevents faults caused by voltage anomalies or short circuits.
Thermal Overload Protection:Prevents module overheating through temperature monitoring.
Fault Feedback:Provides clear visual feedback(such as indicator lights)to indicate operating status and fault conditions.
Efficient and Stable
Conversion efficiency>90%reduces energy loss.
Output current up to 10A meets high load demands.Technical Specifications
Input Voltage:85-264V AC(single-phase)
Output Current:Up to 10A
Frequency Range:47-63Hz
Efficiency:>90%
Operating Temperature:0°C to+55°C
Storage Temperature:-25°C to+85°C
Cooling:Natural convection or fan-assisted
Certifications:CE,UL,RoHS
Mounting:Panel mount within the controller chassis
Dimensions and Weight:Approximately 1000g(depending on model)
