描述
ABB DSQC346U是工业自动化与机器人驱动控制单元卡，属于ABB Advant OCS分布式控制系统组件，主要用于机器人运动控制等领域。以下是其详细信息：
技术参数：
工作电压：24V
输出频率：10/100Mbps
处理速度：50MHz
程序容量：16MB
数据容量：256MB
环境温度：0至60℃
环境湿度：5%至95%，非冷凝
重量：2.3千克
外形尺寸：25.4cm×2.5cm×25.4cm
产品特点：
高性能控制：集成专用处理器，支持精准驱动管理与运动轨迹规划。
工业级可靠性：可适应振动、宽温域等恶劣环境，采用模块化设计，便于维护。
兼容性强：能无缝对接ABB机器人系统及第三方PLC设备。
通信能力好：具备多级通信能力，支持工业以太网及现场总线等通信方式。
功能用途：主要用于控制ABB机器人的伺服电机，例如可控制1轴ABB伺服电机（橙色系列），常安装在配备S4C+控制器的ABB工业机器人机柜中。可实现对机器人运动的精确控制，广泛应用于汽车制造、电子装配等需要机器人作业的自动化生产线场景。
The ABB DSQC346U is a drive control unit card for industrial automation and robotics.It’s a component of the ABB Advant OCS distributed control system and is primarily used in robotic motion control and other fields.The following are its detailed information:
Technical Parameters:
Operating Voltage:24V
Output Frequency:10/100Mbps
Processing Speed:50MHz
Program Capacity:16MB
Data Capacity:256MB
Ambient Temperature:0 to 60°C
Ambient Humidity:5%to 95%,non-condensing
Weight:2.3 kg
Dimensions:25.4cm×2.5cm×25.4cm
Features:
High-Performance Control:Integrated with a dedicated processor,supports precise drive management and motion trajectory planning.
Industrial-Grade Reliability:Adapts to harsh environments such as vibration and a wide temperature range,and features a modular design for easy maintenance.
Strong Compatibility:Seamlessly integrates with ABB robotic systems and third-party PLC devices.
Excellent Communication Capabilities:Equipped with multi-level communication capabilities,it supports industrial Ethernet and fieldbus communication methods.Functional Application:Primarily used to control the servo motors of ABB robots,such as a single-axis ABB servo motor(orange series).This controller is often installed in an ABB industrial robot cabinet equipped with an S4C+controller.It enables precise control of robot motion and is widely used in automated production lines requiring robotics,such as automotive manufacturing and electronics assembly.
