描述
ABB DSQC505是一款电源模块，主要用于为ABB机器人控制系统提供稳定的电源。以下是其产品详情：
基本信息
品牌：ABB
型号：DSQC505
零件号：3HAC4296-1
类型：电源模块
产地：芬兰
技术参数
输入电压：24Vdc（最大4.5A）
输出电压及电流：+3.3V（3-9A）、+5V（8-12A）、+12V（1A）、-12V（0.5A），最大功率88W
功能特点
电源转换：能够将输入的直流电转换为机器人控制系统所需的多种直流电电压，如+3.3V、+5V、+12V、-12V等，为系统中的各个部件提供稳定的电力支持。
信号处理：除了电源转换功能外，DSQC505还涉及信号的采集和处理，这对于机器人的精确控制至关重要。
兼容性强：作为ABB机器人系统的一部分，DSQC505能够与其他模块配合工作，确保整个系统的协同运作，可与ABB S4C+机器人控制器兼容。
机械特性
安装方式：可采用水平或垂直安装方式，支持根据IEC 60715标准的35mm顶帽安装轨安装，也可使用M4螺丝进行安装，紧固扭矩为1.2N・m。
防护等级：PLC系统防护等级为IP20。
外壳材质：外壳符合UL 94 V-2标准。
The ABB DSQC505 is a power module primarily used to provide stable power for ABB robot control systems.Below are product details:
Basic Information
Brand:ABB
Model:DSQC505
Part Number:3HAC4296-1
Type:Power Module
Origin:Finland
Technical Parameters
Input Voltage:24VDC(Maximum 4.5A)
Output Voltage and Current:+3.3V(3-9A),+5V(8-12A),+12V(1A),-12V(0.5A),Maximum Power 88W
Functional Features
Power Conversion:Converts input DC power to the various DC voltages required by the robot control system,such as+3.3V,+5V,+12V,and-12V,providing stable power to various components in the system.
Signal Processing:In addition to power conversion,the DSQC505 also handles signal acquisition and processing,which is crucial for precise robot control.Strong Compatibility:As part of the ABB Robotics system,the DSQC505 works with other modules to ensure coordinated operation of the entire system.It is compatible with the ABB S4C+robot controller.
Mechanical Features
Mounting:It can be mounted horizontally or vertically on a 35mm top-hat rail according to IEC 60715.It can also be mounted using M4 screws with a tightening torque of 1.2N·m.
Protection Rating:The PLC system has an IP20 protection rating.
Enclosure Material:The enclosure complies with UL 94 V-2 standards.
