描述
ABB DSQC697
产品类型：DeviceNet通信板。
通信协议：DeviceNet，传输速率为125Kbps/250Kbps/500Kbps自适应。
接口类型：9针D-sub（支持CAN总线物理层）。
工作温度范围：-20℃至+60℃。
防护等级：IP20。
功能特点：支持ABB IRC5控制器全系列，可扩展至第三方DeviceNet设备；采用双通道冗余设计，内置两套独立通信通道，当主通道故障时自动切换至备用通道，确保数据传输零中断；具备自诊断功能，通过LED指示灯实时显示通信状态，支持ABB RobotStudio软件远程诊断；抗干扰能力强，采用电磁屏蔽技术，可在强电场环境下稳定运行。
ABB DSQC658
产品类型：高级I/O模块。
通道数量：16个数字输入，8个数字输出。
通信协议：EtherCAT。
工作电压：24V DC。
继电器触点额定值：5A 250V AC。
工作温度范围：-20℃至+60℃。
尺寸：100mm x 100mm x 35mm。
重量：0.4kg。
功能特点：采用耐用的铝合金材质，具备良好的散热性能；支持多种数字输入和输出，适用于过程控制和机器安全等多种应用场景；具备电缆故障诊断功能，可监控HTL编码器的输入电缆；提供一个RS-422符合标准的TTL编码器仿真输出和两个数字输入；可通过DIP开关对模块进行设置。
ABB DSQC697
Product Type:DeviceNet Communication Board.
Communication Protocol:DeviceNet,with auto-sensing transmission rates of 125Kbps/250Kbps/500Kbps.
Connector Type:9-pin D-sub(supports CAN bus physical layer).
Operating Temperature Range:-20°C to+60°C.
Protection Rating:IP20.
Features:Supports the full range of ABB IRC5 controllers and is expandable to third-party DeviceNet devices.Features:Dual-channel redundant design with two independent communication channels.Automatically switches to the backup channel in the event of a primary channel failure,ensuring uninterrupted data transmission.Features self-diagnostics with real-time communication status displayed via LED indicators.Supports remote diagnostics using ABB RobotStudio software.Strong anti-interference capabilities and electromagnetic shielding technology ensure stable operation in strong electric field environments.
ABB DSQC658
Product Type:Advanced I/O Module.
Number of Channels:16 digital inputs,8 digital outputs.Communication Protocol:EtherCAT.
Operating Voltage:24V DC.
Relay Contact Rating:5A 250V AC.
Operating Temperature Range:-20°C to+60°C.
Dimensions:100mm x 100mm x 35mm.
Weight:0.4kg.
Features:Made of durable aluminum alloy with excellent heat dissipation;supports a variety of digital inputs and outputs,suitable for various applications such as process control and machine safety;features cable fault diagnostics for monitoring HTL encoder input cables;provides one RS-422 compliant TTL encoder emulation output and two digital inputs;module configuration is adjustable via DIP switches.
