描述
产品概述
ABB DSRF197K01是一款高性能伺服控制器，专为工业自动化领域设计，采用数字控制技术，具备高速高精度的运动控制能力。其紧凑型设计（体积小、易安装）支持多种控制模式，广泛应用于自动化生产线、机器人、数控机床、印刷机械等领域。
核心功能与技术特点
1.高精度运动控制
控制算法：通过独特的数字控制算法实现高精度定位和速度控制，适用于对精度要求苛刻的场景。
多模式支持：兼容多种运动控制模式（如点位控制、连续路径控制等），适应不同应用场景需求。
2.硬件设计优势
紧凑结构：体积小巧，便于集成到设备中，减少安装空间占用。
易维护性：模块化设计简化维护流程，降低故障排查难度。
3.扩展功能（关联模块）
以太网通信：支持IEEE802.3标准（10BaseT），传输速率达10 MBit/s，可集成到工业网络中实现远程监控与数据采集。
触摸屏交互：兼容模块化触摸屏（如Panel 800系列），支持高分辨率显示与多协议连接，提升操作便捷性。
技术参数
参数类别规格
控制类型伺服运动控制
控制模式多模式（点位、连续路径等）
数字信号处理高速CPU，支持直接内存访问（DMA）以降低通信开销
电源要求输入电压110V-380V（以太网模块）
环境适应性工业级防护，适应温度范围-10°C至+60°C
认证标准符合工业设备通用安全认证（如CE、UL）
Product Overview
The ABB DSRF197K01 is a high-performance servo controller designed for the field of industrial automation,adopts digital control technology,and has high-speed and high-precision motion control capabilities.Its compact design(small size and easy to install)supports a variety of control modes and is widely used in fields such as automated production lines,robots,CNC machine tools,printing machinery,etc.
Core functions and technical features
1.High-precision motion control
Control algorithm:High-precision positioning and speed control are achieved through unique digital control algorithms,suitable for scenarios with strict accuracy requirements.
Multi-mode support:compatible with multiple motion control modes(such as point control,continuous path control,etc.),adapting to the needs of different application scenarios.
2.Hardware design advantages
Compact structure:small size,easy to integrate into the equipment and reduce installation space.
Ease of maintenance:Modular design simplifies maintenance processes and reduces the difficulty of troubleshooting.
3.Extended functions(associated modules)
Ethernet communication:supports IEEE802.3 standard(10BaseT),with a transmission rate of up to 10 MBit/s,and can be integrated into industrial networks to achieve remote monitoring and data acquisition.
Touch screen interaction:compatible with modular touch screens(such as Panel 800 series),supports high-resolution display and multi-protocol connection,improving operational convenience.
Technical parameters
Parameter Category Specifications
Control Type Servo Motion Control
Control mode Multi-mode(points,continuous paths,etc.)
Digital signal processing High-speed CPU,supports direct memory access(DMA)to reduce communication overhead
Power supply requirements Input voltage 110V-380V(Ethernet module)
Environmental adaptability Industrial-grade protection,adapted to temperature range-10°C to+60°C
Certification standards Comply with general safety certification of industrial equipment(such as CE,UL)
