ABB DSTA 131 57120001-CV产品详情
产品概述
ABB DSTA 131是一款来自ABB公司的变频器整流器控制板。该板卡是ABB ACS600和ACS800等系列工业变频器中的一个关键组件，特别适用于**可再生（Regenerative）**或四象限变频器，其主要功能是控制电能的双向流动。
主要特性与规格
产品类型：整流器控制板/整流单元
零件号：DSTA 131，完整零件代码为57120001-CV
制造商：ABB
兼容系统：主要用于ABB的ACS600和ACS800系列工业变频器，特别是需要将制动能量回馈电网的型号。
功能：
能量回馈控制：在电机处于制动或减速状态时，该板卡能够将产生的电能（再生能量）有效控制并回馈到电网，而非以热量的形式消耗掉。
电压和电流管理：负责监测和控制整流器环节的电压和电流，确保能量回馈过程平稳、高效且安全。
通信与诊断：与变频器的主控板进行通信，并能够报告整流器单元的状态和故障信息。
物理和电气参数：
设计：典型的模块化电路板设计，安装在变频器内部的整流单元槽位中。
应用领域与产品状态
作为ABB变频器系统的关键组件，DSTA 131板卡广泛应用于：
工业传动：在需要频繁启停、快速加减速或有势能负载的应用中，例如起重机、电梯、离心机和测试台架等。
设备维护：该模块是ACS600/ACS800系列变频器中最关键的备件之一，用于维修或更换因故障而影响变频器性能的控制板。
ABB DSTA 131 57120001-CV Product Details
Product Overview
The ABB DSTA 131 is a converter rectifier control board from ABB.This board is a key component in ABB’s ACS600 and ACS800 series industrial drives,particularly suitable for regenerative or four-quadrant drives.Its primary function is to control the bidirectional flow of electrical energy.
Key Features and Specifications
Product Type:Rectifier Control Board/Rectifier Unit
Part Number:DSTA 131,full part code:57120001-CV
Manufacturer:ABB
Compatible Systems:Primarily for ABB’s ACS600 and ACS800 series industrial drives,particularly those that require regenerative braking energy to be fed back into the grid.
Function:
Energy Regeneration Control:When the motor is braking or decelerating,this board effectively controls and feeds the generated electrical energy(regenerative energy)back into the grid,rather than dissipating it as heat.
Voltage and Current Management:Responsible for monitoring and controlling the voltage and current in the rectifier stage,ensuring a smooth,efficient,and safe energy regeneration process.
Communication and Diagnostics:Communicates with the inverter’s main control board and reports rectifier unit status and fault information.
Physical and Electrical Parameters:
Design:A typical modular circuit board design,installed in the rectifier unit slot within the inverter.
Applications and Product Status
As a key component of ABB drive systems,the DSTA 131 board is widely used in:
Industrial Drives:Applications with frequent starting and stopping,rapid acceleration and deceleration,or loads with potential energy,such as cranes,elevators,centrifuges,and test benches.
Equipment maintenance:This module is one of the most critical spare parts in the ACS600/ACS800 series inverters and is used to repair or replace the control board that affects the inverter performance due to faults.
