描述
ABB DSTS103是一款应用于工业自动化领域的产品，有触发脉冲放大器和模拟量控制模块等不同类型，以下是具体详情：
DSTS103触发脉冲放大器：
功能：用于产生和放大触发脉冲信号，以控制相关设备的运行，可通过跳线S1（AI1）和S2（AI2）进行设置。
电气参数：最大开关电流为80A/120V DC，辅助电压为+48V DC，信号范围为电流0（4）-20mA，电压0（2）-10V。
物理特性：原产于瑞典，重量约0.3kg。
安装连接：通过控制接口卡SNAT 7600/7640上的X50螺丝端子连接，支持RS485串行通信总线，可通过控制接口卡上的X51端子连接（该端子可能已连接到控制柜外的可选端子块X2）。
DSTS103模拟量控制模块（Analog Back）：
功能：是一种高精度控制模块，用于工业自动化领域，可与各种传感器和执行器进行数据交换，实现对温度、压力等参数的精确控制。
工作电压：DC 24V。
信号范围：0-10V。
输入输出能力：具有4个模拟量输入和2个模拟量输出。
通信接口：RS485 Modbus。
工作温度：-25℃至+55℃。
存储温度：-40℃至+70℃。
物理尺寸：102mm×102mm×98mm，重量约0.45kg。
ABB DSTS103 is a product used in the field of industrial automation.It has different types such as trigger pulse amplifier and analog control module.The following are the specific details:
DSTS103 trigger pulse amplifier:
Function:Used to generate and amplify trigger pulse signals to control the operation of related equipment.It can be set through jumpers S1(AI1)and S2(AI2).
Electrical parameters:Maximum switching current is 80A/120V DC,auxiliary voltage is+48V DC,signal range is current 0(4)-20mA,voltage 0(2)-10V.
Physical characteristics:Originating in Sweden,weighs about 0.3kg.
Installation connection:Connected through the X50 screw terminal on the control interface card SNAT 7600/7640,supports RS485 serial communication bus,and can be connected through the X51 terminal on the control interface card(this terminal may be connected to the optional terminal block X2 outside the control cabinet).
DSTS103 Analog Control Module(Analog Back):
Function:This high-precision control module is used in industrial automation.It can exchange data with various sensors and actuators,enabling precise control of parameters such as temperature and pressure.
Operating voltage:DC 24V.
Signal range:0-10V.
Input and output capabilities:4 analog inputs and 2 analog outputs.
Communication interface:RS485 Modbus.
Operating temperature:-25°C to+55°C.
Storage temperature:-40°C to+70°C.
Physical dimensions:102mm×102mm×98mm,weight:approximately 0.45kg.
