描述
ABB DX522是一款数字输入输出模块，常用于工业自动化控制系统，以下是其产品详情：
基本信息
型号：DX522，细分型号有DX522-XC等。
产品ID：1SAP445200R0001等。
品牌：ABB
模块类型：数字输入输出模块
原产国：瑞典
尺寸：约76mm×67.5mm×62mm
重量：约0.177kg
技术参数
输入点数：8
输入电压：24VDC
输入电流：5mA
最大输入电压：0-30V
输出点数：8
输出类型：继电器
输出电压：230VAC
输出电流：3A
延迟时间：0.1-32ms
供电电压：20.4-28.8VDC
防护等级：IP20
工作温度范围：-30℃至+70℃
存储温度范围：-40℃至+85℃
功能特点
信号处理：具备8路24VDC数字输入和8路继电器输出，可实现数字信号的采集与控制指令的输出。
通信能力：支持RS-485 Modbus等通信协议，方便与其他设备进行数据交换和通信。
配置灵活：通道可单独配置为输入或输出，适用于多种工业场景。
安装方式：可用于AC500系列PLC的中央扩展，也可通过通信接口模块进行分布式扩展。
The ABB DX522 is a digital input/output module commonly used in industrial automation control systems.Below are its product details:
Basic Information
Model:DX522,with sub-models such as DX522-XC.
Product ID:1SAP445200R0001,etc.
Brand:ABB
Module Type:Digital I/O Module
Country of Origin:Sweden
Dimensions:Approximately 76mm×67.5mm×62mm
Weight:Approximately 0.177kg
Technical Parameters
Number of Inputs:8
Input Voltage:24VDC
Input Current:5mA
Maximum Input Voltage:0-30V
Number of Outputs:8
Output Type:Relay
Output Voltage:230VAC
Output Current:3A
Delay Time:0.1-32ms
Supply Voltage:20.4-28.8VDC
Protection Rating:IP20
Operating Temperature Range:-30°C to+70°C
Storage Temperature Range:-40°C to+85°C
Functional Features
Signal Processing:8 24VDC digital inputs and 8 relay outputs,enabling digital signal acquisition and control command output.
Communication Capabilities:Supports RS-485,Modbus,and other communication protocols,facilitating data exchange and communication with other devices.Flexible Configuration:Channels can be individually configured as input or output,suitable for a variety of industrial scenarios.
Installation:Can be used for central expansion of AC500 series PLCs or distributed expansion via communication interface modules.
