描述
ABB DX581-S 1SAP284100R0001是一款安全数字输入/输出模块，属于S500-S系列。以下是其产品详情：
基本信息
品牌：ABB
型号：DX581-S 1SAP284100R0001
产品类型：安全数字输入/输出模块
产地：瑞典
尺寸：67.5mm×76mm×62mm（宽×高×长）
重量：0.13kg（净重），0.159kg（毛重）
技术参数
输入参数：8个安全数字输入（SDI），输入电压为24VDC，输入电流为7mA，其中4个SDI通道的安全完整性等级可达SIL3（带差异时间监控），另外4个SDI通道的安全完整性等级为SIL2，输入滤波器可配置为1ms、2ms、5ms…500ms。
输出参数：8个安全数字输出（SDO），输出电压范围为20.4-28.8VDC，输出电流最大为0.5A/通道，安全完整性等级可达SIL2/SIL3，具备4个脉冲输出，用于系统诊断和控制。
电源电压：20.4-28.8VDC
防护等级：IP20
功能特点
高安全性：支持SIL2和SIL3安全等级，适用于对安全要求较高的工业自动化系统。
配置灵活：输入滤波器和延迟时间可根据实际应用需求进行配置。
诊断功能：4个脉冲输出可用于系统诊断和控制，便于检测和维护。
通信接口：可通过PROFINET通信接口模块（如CI501-P NIO、CI502-P NIO等）进行通信，支持PROFIsafe V2协议。
The ABB DX581-S 1SAP284100R0001 is a safety digital input/output module,part of the S500-S series.The following are product details:
Basic Information
Brand:ABB
Model:DX581-S 1SAP284100R0001
Product Type:Safety Digital Input/Output Module
Origin:Sweden
Dimensions:67.5mm×76mm×62mm(W×H×D)
Weight:0.13kg(net),0.159kg(gross)
Technical Parameters
Input Parameters:8 safety digital inputs(SDIs),24VDC input voltage,7mA input current.Four SDI channels are capable of SIL3(with discrepancy time monitoring),while the remaining four SDI channels are capable of SIL2.The input filter is configurable to 1ms,2ms,5ms,or 500ms.Output Parameters:8 safe digital outputs(SDOs),with an output voltage range of 20.4-28.8 VDC and a maximum output current of 0.5 A per channel.Safety integrity levels up to SIL2/SIL3 are supported,along with four pulse outputs for system diagnostics and control.
Power Supply Voltage:20.4-28.8 VDC
Protection Rating:IP20
Features:High Safety:Supports SIL2 and SIL3 safety levels,making it suitable for industrial automation systems with high safety requirements.
Flexible Configuration:Input filters and delay times can be configured to meet specific application requirements.
Diagnostic Function:Four pulse outputs can be used for system diagnostics and control,facilitating inspection and maintenance.
Communication Interface:Communication is possible via PROFINET communication interface modules(such as the CI501-P NIO and CI502-P NIO),supporting the PROFIsafe V2 protocol.
