描述
ABB EL3020是一款属于EasyLine系列的连续气体分析仪，主要用于工业过程控制、环境监测等领域。以下是其产品详情：
测量原理：采用非色散红外线（NDIR）技术，部分型号结合紫外线（UV）或电化学传感器。
测量范围：根据配置的传感器不同，可覆盖多种气体成分，如CO、CO₂、NO、SO₂、NH₃、H₂O、CH₄及其他碳氢化合物等。
技术参数
电源：100-240VAC±10%，48-63Hz。
功耗：单通道约40VA，双通道约70VA。
模拟输出：0/2/4-20mA（负载750Ω）。
线性误差：±0.5%FS（满量程）。
响应时间：<3秒。
测量漂移：±1%FS/周。
产品特点
高精度测量：采用先进的光学系统和信号处理技术，确保测量结果的准确性和可靠性。
多组分测量：单台分析仪最多可同时对五种气体成分进行精准检测，满足复杂工况下多样化的气体分析需求。
模块化设计：结构紧凑，易于安装和维护，降低了成本和时间。
操作简便：人机界面友好，配备简洁的5键式菜单驱动操作界面，搭配240×160像素的背光图形显示屏，可清晰显示测量数值、测量趋势等。
多种通信接口：支持以太网、Modbus、Profibus等接口，方便与其他设备集成。
应用领域
能源行业：用于发电厂、锅炉、燃烧器等的气体分析，确保运行效率和安全性。
化工行业：监测化工生产过程、废气处理中的气体成分。
冶金行业：可用于高炉、转炉等场所的气体监测。
食品饮料行业：如包装气体检测、发酵过程监测等。
环境保护：适用于环境空气质量监测、污染源监测等。
The ABB EL3020 is a continuous gas analyzer in the EasyLine series,primarily used in industrial process control and environmental monitoring.The following are product details:
Measurement Principle:Utilizes non-dispersive infrared(NDIR)technology,with some models incorporating ultraviolet(UV)or electrochemical sensors.
Measurement Range:Depending on the configured sensor,it covers a wide range of gas components,including CO,CO₂,NO,SO₂,NH₃,H₂O,CH₄,and other hydrocarbons.
Technical Parameters
Power Supply:100-240VAC±10%,48-63Hz.
Power Consumption:Approximately 40VA for a single channel,approximately 70VA for a dual channel.
Analog Output:0/2/4-20mA(750Ωload).
Linearity Error:±0.5%FS(full scale).
Response Time:<3 seconds.
Measurement Drift:±1%FS/week.Product Features
High-Precision Measurement:Utilizes advanced optical systems and signal processing technologies to ensure accurate and reliable measurement results.
Multi-Component Measurement:A single analyzer can simultaneously and accurately measure up to five gas components,meeting diverse gas analysis needs under complex operating conditions.
Modular Design:Compact design allows for easy installation and maintenance,reducing costs and time.
Easy Operation:A user-friendly interface features a simple,5-button,menu-driven user interface and a 240×160 pixel backlit graphical display for clear display of measurement valuesand trends.
Multiple Communication Interfaces:Supports Ethernet,Modbus,and Profibus interfaces for easy integration with other devices.
Applications
Energy Industry:Suitable for gas analysis in power plants,boilers,and burners,ensuring operational efficiency and safety.
Chemical Industry:Monitoring gas composition in chemical production processes and waste gas treatment.
Metallurgical Industry:Suitable for gas monitoring in blast furnaces,converters,and other locations.
Food and Beverage Industry:Suitable for packaging gas detection and fermentation process monitoring.Environmental protection:Applicable to ambient air quality monitoring,pollution source monitoring,etc.
