描述
ABB EM010-9318是一款牵引电压传感器，以下是其产品详情：
基本信息
品牌：ABB
产地：瑞典
尺寸：8.2cm×5.3cm×6.5cm
重量：0.2kg
技术参数
额定一次电压：2000V
测量范围（峰值）：±3000V
一次匝数：20000
二次匝数：2000
在额定一次电压下的二次电流：50mA
电源电压：±12至±24V DC
精度（在额定一次电压下，25℃时）：≤±1%
失调电流（25℃时）：≤±0.3mA
线性度：≤±0.1%
热漂移系数（-25…+70℃）：≤100µA/℃
延迟时间：≤100µs
工作温度范围：-40℃至+85℃
存储温度范围：-40℃至+85℃
The ABB EM010-9318 is a traction voltage sensor.Product details are as follows:
Basic Information
Brand:ABB
Origin:Sweden
Dimensions:8.2cm×5.3cm×6.5cm
Weight:0.2kg
Technical Parameters
Rated primary voltage:2000V
Measuring range(peak):±3000V
Number of primary turns:20,000
Number of secondary turns:2000
Secondary current at rated primary voltage:50mA
Supply voltage:±12 to±24V DC
Accuracy(at rated primary voltage,25°C):≤±1%
Offset current(at 25°C):≤±0.3mA
Linearity:≤±0.1%
Thermal drift coefficient(-25…+70°C):≤100µA/°C
Delay time:≤100µs
Operating temperature range:-40°C to+85°C
Storage temperature range:-40°C to+85°C
