描述
ABB FAU810是一款火焰分析装置，C87-11006可能是其相关的订货号或模块编号等。以下是FAU810的产品详情：
基本信息
品牌：ABB
产品类型：火焰分析单元模块
技术规格
信号处理：内置两个独立放大器，可同时接收并处理两个火焰检测器探头信号，每个通道具备独立的火焰继电器及4-20mA模拟量输出。
通信接口：支持冗余Profi总线DP-V1，传输速率高达12Mbit/sec，也支持标准Modbus接口，可连接255个节点，速率为115Kbit/s。
电气特性：单电源供电范围为21.6V至31.2VDC，功耗标准为6W，内置电源隔离二极管，支持冗余电源配置。
环境适应性：工作温度范围为0°C至60°C，湿度95%非凝结，防护等级IP66（NEMA 4），防爆等级ATEXⅡ2GD Ex dⅡCT6。
功能特点
全光谱检测：兼容红外线（920nm峰值）、紫外线（280nm响应）及可见光型探头，实现全光谱火焰监测。
智能分析：专利燃料数据库与自动调谐功能结合，动态优化火焰识别算法，信号准确率提升30%以上，支持多套参数自动选择，针对不同燃料工况实时调整检测参数。
冗余设计：双通道独立运行，单个通道故障时系统仍可维持基本监测功能，连续自检功能覆盖火焰检测器及电子元件，故障诊断响应时间≤0.1秒。
外观与操作
显示与操作：配备图形LCD显示模块，可显示4行20个字符和多个条形图，有4个编程按钮（编程、显示、向上和向下）。
状态指示：4个状态指示灯（电源、火焰#1、火焰#2、火焰#3或故障），程序锁定可通过本地DIP开关选择，可通过RS-485链接和Flame Explorer软件对功能进行远程编程。
The ABB FAU810 is a flame analysis unit.C87-11006 may be its associated order number or module number.The following are product details for the FAU810:
Basic Information
Brand:ABB
Product Type:Flame Analysis Unit
Technical Specifications
Signal Processing:Two built-in independent amplifiers simultaneously receive and process signals from two flame detector probes.Each channel has an independent flame relay and 4-20mA analog output.
Communication Interface:Supports redundant Profibus DP-V1 with a transmission rate of up to 12Mbit/sec.It also supports a standard Modbus interface,capable of connecting 255 nodes at a rate of 115Kbit/sec.
Electrical Characteristics:Single power supply range is 21.6V to 31.2VDC,with a typical power consumption of 6W.Built-in power isolation diodes support redundant power supply configurations.Environmental Adaptability:Operating temperature range:0°C to 60°C,humidity:95%non-condensing,IP66(NEMA 4)protection rating,ATEX II 2GD Ex d IICT6 explosion-proof rating.
Features
Full-spectrum Detection:Compatible with infrared(920nm peak),ultraviolet(280nm response),and visible light sensors,enabling full-spectrum flame monitoring.
Intelligent Analysis:A patented fuel database combined with auto-tuning dynamically optimizes the flame identification algorithm,improving signal accuracy by over 30%.Multiple parameter sets are automatically selected,allowing real-time adjustment of detection parameters for different fuel conditions.
Redundant Design:Dual channels operate independently,ensuring the system maintains basic monitoring functionality even if a single channel fails.Continuous self-test covers the flame detector and electronics,ensuring a fault diagnosis response time of≤0.1 second.Appearance and Operation
Display and Operation:Equipped with a graphical LCD display module with a 4-line,20-character display and multiple bar graphs,and four programming buttons(Program,Display,Up,and Down).
Status Indication:Four status indicators(Power,Flame#1,Flame#2,Flame#3,or Fault).Program lockout is selectable via a local DIP switch,and functions can be remotely programmed via an RS-485 link and Flame Explorer software.
