描述
ABB FAU810是一款火焰分析单元，主要用于工业火焰检测领域。以下是其产品详情：
基本信息
品牌：ABB
产品类型：火焰分析单元
技术规格
信号输出：提供两个4-20mA信号，可独立监视火焰强度、频率、质量和火焰交流幅值。
火焰继电器：有/无火延时时间可设置0.1-10秒；火焰继电器数量为三个，接点容量250Vac、3A、750VA；220Vdc、300mA、66W。
串行数据通讯：两个隔离的RS-485通讯接口，用于冗余通讯，串行数据格式为MODBUS（缺省）、PROFIBUS DP-V1（可设定）。
自检周期：0.1S。
环境温度：0°C-60°C，95%非凝结。
耗电量：最小4W，最大10W，标准6W。
产品特点
双信道设计：可同时接收两个检测器探头信号，每个探头信号被送入独立的信道，每个信道拥有自己的火焰继电器以及4-20mA的模拟输出，确保火焰检测的准确性和可靠性。
智能检测与分析：能够根据不同的燃料工况自动选择参数，无需像传统火检那样由于运行工况变化和燃料的变化而不断“学习”并频繁调整参数。还可实时反映火焰燃烧的真实状况，显示瞬时火焰的闪烁频率、辐射强度以及火焰品质等数据。
高安全性与可靠性：能够持续运行以保证燃烧器控制的安全可靠，当逻辑判断存在不安全状况时，如无火焰状况，装置会发出信号。采用冗余Profi总线DP-V1或标准Modbus接口，可轻松安全地进行数据交换和调整。
易于安装与配置：FAU810易于安装和配置，操作简便，可以与所有ABB火焰检测器配合使用，成为所有ABB火焰扫描仪应用的标准模块，也是对现有设备进行改造的首选解决方案。
The ABB FAU810 is a flame analysis unit primarily used for industrial flame detection.Here are its product details:
Basic Information
Brand:ABB
Product Type:Flame Analysis Unit
Technical Specifications
Signal Output:Provides two 4-20mA signals,allowing independent monitoring of flame intensity,frequency,quality,and AC amplitude.
Flame Relay:Flame/no-flame delay time is adjustable from 0.1 to 10 seconds;three flame relays with a contact rating of 250Vac,3A,750VA;220Vdc,300mA,66W.
Serial Communication:Two isolated RS-485 communication ports for redundant communication;serial data format is MODBUS(default),PROFIBUS DP-V1(configurable).
Self-test Cycle:0.1 seconds.
Ambient Temperature:0°C to 60°C,95%non-condensing.
Power Consumption:Minimum 4W,maximum 10W,typical 6W.
Product Features
Dual Channel Design:Can simultaneously receive signals from two detectors;each detector signal is processed in a separate channel,each with its own flame relay and 4-20mA analog output,ensuring accurate and reliable flame detection.
Intelligent Detection and Analysis:Automatically selects parameters based on different fuel conditions,eliminating the need for continuous parameter adjustments as with traditional flame detectors.Provides real-time data on flame characteristics,including instantaneous flame flicker frequency,radiation intensity,and flame quality.
High Safety and Reliability:Ensures safe and reliable burner control;the device signals an unsafe condition,such as no flame,when detected.Redundant ProfiBus DP-V1 or standard Modbus interface allows for easy and secure data exchange and adjustment.
Easy Installation and Configuration:The FAU810 is easy to install and configure,and compatible with all ABB flame detectors.It is a standard module for all ABB flame scanner applications and an ideal solution for retrofitting existing equipment.
