描述
ABB G7BGA HENF105334R0010是ABB NF系列中的一款接触器式中间继电器。以下是其产品详情：
产品特点
极数选择：提供4极和8极型号可选，8极型号带永久固定4极辅助触点。
连接方式：支持螺钉、弹簧以及环型连接，方便不同场景下的接线需求。
浪涌抑制：内置浪涌抑制器，可有效保护继电器及周边电路免受浪涌电压的冲击。
电压适应性：采用电子线圈接口，交、直流操作，适应的控制电压范围很宽，如100-250V AC/DC，仅4个控制电压规格便可覆盖24-250V 50/60Hz和12-250V DC，还允许直接由PLC输出的24V DC 500mA信号控制。
低功耗：具有降低线圈功耗的特点，独特的点电压分合动作特性，可抵抗短时的电压跌落和中断，符合SEMI F47-0706标准。
触点结构：以常见的NFZ 8极中间继电器为例，其具有机械联动触点结构，13、14为线圈引脚，9、10、11、12是公共点，1与9是常闭、5与9是常开，2与10是常闭、6与10是常开，3与11是常闭、7与11是常开，4与12是常闭、8与12是常开。
应用领域：NF系列中间继电器可应用于各个国家及地区，兼容所有类型的电网，适用于各种需要接通、断开辅助回路和控制回路的场景，如工业自动化控制系统、电力系统、建筑电气等领域。
The ABB G7BGA HENF105334R0010 is a contactor relay in the ABB NF series.The following are product details:
Features
Pole Options:Available in 4-pole and 8-pole models,the 8-pole model features permanently fixed 4-pole auxiliary contacts.
Connection Methods:Supports screw,spring,and ring connections,facilitating wiring requirements in various scenarios.
Surge Suppression:A built-in surge suppressor effectively protects the relay and surrounding circuits from surge voltages.
Voltage Compatibility:Utilizing an electronic coil interface for AC and DC operation,it accommodates a wide control voltage range,including 100-250V AC/DC.With just four control voltage specifications,it covers 24-250V 50/60Hz and 12-250V DC.It also supports direct control from a 24V DC 500mA PLC output signal.Low Power Consumption:The NF series relays feature reduced coil power consumption.Their unique point voltage switching characteristics provide resistance to short voltage drops and interruptions,complying with SEMI F47-0706 standards.
Contact Structure:Taking the common NFZ 8-pole relay as an example,they feature a mechanically linked contact structure.Pins 13 and 14 are coil pins,while pins 9,10,11,and 12 are common points.Pins 1 and 9 are normally closed,while pins 5 and 9 are normally open.Pins 2 and 10 are normally closed,while pins 6 and 10 are normally open.Pins 3 and 11 are normally closed,while pins 7 and 11 are normally open.Pins 4 and 12 are normally closed,while pins 8 and 12 are normally open.
Applications:The NF series relays can be used in various countries and regions,are compatible with all types of power grids,and are suitable for connecting and disconnecting auxiliary and control circuits,such as in industrial automation control systems,power systems,and building electrical systems.
