描述
1.核心功能与定位
模块类型：结合ABB AC 800M系列的技术架构，该模块应属于数字量输出模块，用于将控制器的数字信号转换为现场设备（如继电器、电磁阀）的驱动信号。
信号处理：
输出通道：推测为16路或32路24V DC晶体管输出（参考同类模块如GJR2385100R1041），支持干接点或负载驱动。
隔离设计：电气隔离保护（隔离电压≥500V DC），增强抗干扰能力。
负载能力：单通道最大输出电流通常为0.5-2A（需结合具体型号确认）。
通信接口：通过CS31系统总线与AC 800M控制器通信，支持Modbus协议（需搭配CI854等通信模块实现）。
2.硬件设计与参数
供电要求：24V DC电源输入，功耗通常在5-10W之间（参考同类模块）。
安装方式：支持DIN导轨或螺丝固定，尺寸约为100mm×125mm×50mm（紧凑型设计）。
诊断功能：LED指示灯实时显示通道状态、电源及通信连接情况（参考GJR2385100R1041的设计）。
1.Core Function and Positioning
Module Type:Based on the technical architecture of the ABB AC800M series,this module is a digital output module used to convert digital signals from the controller into drive signals for field devices(such as relays and solenoid valves).
Signal Processing:
Output Channels:Expected to be 16 or 32 24V DC transistor outputs(refer to similar modules such as GJR2385100R1041),supporting dry contacts or load driving.
Isolation Design:Electrical isolation protection(isolation voltage≥500V DC)enhances anti-interference capabilities.
Load Capacity:The maximum output current per channel is typically 0.5-2A(to be confirmed based on the specific model).
Communication Interface:Communicates with the AC800M controller via the CS31 system bus and supports the Modbus protocol(requires a communication module such as the CI854).
2.Hardware Design and Parameters
Power Requirements:24V DC power input,power consumption typically between 5-10W(refer to similar modules).Mounting:Supports DIN rail or screw mounting.Dimensions:Approximately 100mm×125mm×50mm(compact design).
Diagnostic Features:LED indicators display real-time channel status,power supply,and communication connection status(refer to the design of GJR2385100R1041).
