描述
ABB IMASI03是一款通用模拟输入从模块，属于ABB Bailey Infi 90系列，主要用于工业自动化控制系统中模拟信号的采集和处理。以下是其产品详情：
基本信息
品牌：ABB
类型：模拟输入从模块
重量：约0.36-0.7千克
尺寸：约95mm×90mm×40mm或330mm×51mm×178mm
工作电压：24VDC
技术参数
输入范围：-10V至+10V、0至20mA、4至20mA
精度：±0.1%
分辨率：16位
通道数量：8通道
数据传输速率：高达2.5Mbps
隔离：通道和电源之间1500VDC
采样率：100sps
工作温度范围：-20°C至+85°C
功能特点
高精度与高分辨率：采用先进的电路设计和信号处理技术，确保了高精度和高分辨率，能准确采集和处理模拟信号。
宽输入范围：支持多种模拟信号输入范围，可满足不同类型传感器和设备的需求。
电流隔离：通道和电源之间的隔离设计，有效防止信号干扰和电气故障，提高了系统的稳定性和可靠性。
可编程增益放大器：可根据实际应用需求，通过编程设置不同的增益倍数，灵活调整输入信号的放大比例。
开路输入检测：具备开路输入检测功能，能够及时发现输入回路中的开路故障，便于系统的维护和故障排查。
状态指示灯：每个通道都配备了状态LED灯，可直观显示通道的工作状态，方便用户进行监控和诊断。
DIN导轨安装：采用标准的DIN导轨安装方式，安装简便，节省空间，便于在工业控制柜中进行布局和安装。
ABB IMASI03 is a universal analog input slave module belonging to the ABB Bailey Infi 90 series.It is mainly used for analog signal acquisition and processing in industrial automation control systems.The following are product details:
Basic Information
Brand:ABB
Type:Analog Input Slave Module
Weight:Approximately 0.36-0.7 kg
Dimensions:Approximately 95 mm×90 mm×40 mm or 330 mm×51 mm×178 mm
Operating Voltage:24 VDC
Technical Parameters
Input Range:-10 V to+10 V,0 to 20 mA,4 to 20 mA
Accuracy:±0.1%
Resolution:16 bits
Number of Channels:8
Data Transfer Rate:Up to 2.5 Mbps
Isolation:1500 VDC between channels and power supply
Sampling Rate:100 sps
Operating Temperature Range:-20°C to+85°C
Features
High Precision and High Resolution:Advanced circuit design and signal processing technology ensure high precision and high resolution,enabling accurate acquisition and processing of analog signals.
Wide Input Range:Supports a variety of analog signal input ranges to meet the needs of different types of sensors and devices.Galvanic Isolation:Isolation between the channels and the power supply effectively prevents signal interference and electrical faults,improving system stability and reliability.
Programmable Gain Amplifier:The gain factor can be programmed to flexibly adjust the input signal amplification ratio based on actual application requirements.
Open Input Detection:The open input detection function promptly detects open circuit faults in the input circuit,facilitating system maintenance and troubleshooting.
Status Indicator:Each channel is equipped with a status LED that visually displays the channel’s operating status,facilitating user monitoring and diagnostics.
DIN Rail Mounting:Standard DIN rail mounting is adopted for easy installation,saving space,and facilitating layout and installation in industrial control cabinets.
