描述
ABB IMASI23是一款模拟量输入模块，属于ABB Symphony系列和Harmony家族，常用于工业自动化控制系统中。以下是其产品详情：
产品型号：IMASI23
产品类型：模拟量输入模块
输入通道数：16通道
输入信号类型：支持电压（0-10V）、电流（4-20mA）、热电偶（Type J/K/N/E等）、毫伏信号、电阻温度检测器（RTD）等多种信号。
精度：±0.1%FS（满量程）
分辨率：24位
工作温度范围：-20°C至+60°C
存储温度范围：-40°C至+85°C
通信协议：Modbus RTU
数据通信线路：RS-485总线
尺寸：100mm x 100mm x 30mm
重量：0.2kg
认证：CE、UL、CSA、EN61000-6-2、EN61000-6-4
该模块采用隔离设计，每个通道配备独立的模拟数字转换器和信号隔离电路，可避免信号干扰，还支持通过软件对每个通道的输入类型、量程进行独立设置。其主要作用是实现工业过程中的数据采集与传输，广泛应用于工业自动化控制、能源管理、过程控制和楼宇自动化等领域。
The ABB IMASI23 is an analog input module from the ABB Symphony and Harmony families,commonly used in industrial automation control systems.Below are the product details:
Model:IMASI23
Type:Analog Input Module
Number of Input Channels:16
Input Signal Type:Supports voltage(0-10V),current(4-20mA),thermocouples(Type J/K/N/E,etc.),millivolt signals,resistance temperature detectors(RTDs),and other signals.Accuracy:±0.1%FS(Full Scale)
Resolution:24-bit
Operating Temperature Range:-20°C to+60°C
Storage Temperature Range:-40°C to+85°C
Communication Protocol:Modbus RTU
Data Communication Line:RS-485 Bus
Dimensions:100mm x 100mm x 30mm
Weight:0.2kg
Certifications:CE,UL,CSA,EN61000-6-2,EN61000-6-4
This module features an isolated design,with each channel equipped with an independent analog-to-digital converter and signal isolation circuitry to prevent signal interference.The input type and range of each channel can be independently configured via software.It is primarily used for data acquisition and transmission in industrial processes and is widely used in industrial automation control,energy management,process control,and building automation.
