描述
ABB IMASI23是一款高性能的模拟输入模块，属于ABB Ability™系列，适用于ABB的Symphony系列和Harmony家族，主要用于工业自动化控制系统。以下是其产品详情：
基本信息
品牌：ABB
输入通道数：16通道
重量：约0.2kg
尺寸：100mm x 100mm x 30mm
工作电压：24VDC
认证：CE、UL、CSA、EN61000-6-2、EN61000-6-4
技术参数
输入信号类型：电压（0-10V）、电流（4-20mA）、热电偶（Type J/K/N/E等）、毫伏信号、电阻温度检测器（RTD）等。
精度：±0.1%FS（满量程）
工作温度范围：-20°C至+60°C
存储温度范围：-40°C至+85°C
通信协议：Modbus RTU
功能特点
高精度信号采集：采用24位高分辨率ADC，确保信号采集的精确性。
多种信号支持：支持多种工业信号类型，可满足不同工业场景的需求。
隔离设计：每个通道配备独立的模拟数字转换器和信号隔离电路，避免信号干扰，提高系统稳定性。
灵活配置：支持通过软件对每个通道的输入类型、量程进行独立设置，方便用户根据实际需求进行配置。
通信兼容性：兼容Modbus RTU等多种工业通信协议，易于与其他系统集成。
The ABB IMASI23 is a high-performance analog input module from the ABB Ability™family.It’s compatible with ABB’s Symphony and Harmony families and is primarily used in industrial automation control systems.Product details are as follows:
Basic Information
Brand:ABB
Input Channels:16
Weight:Approximately 0.2kg
Dimensions:100mm x 100mm x 30mm
Operating Voltage:24VDC
Certifications:CE,UL,CSA,EN61000-6-2,EN61000-6-4
Technical Parameters
Input Signal Types:Voltage(0-10V),Current(4-20mA),Thermocouples(Type J/K/N/E,etc.),Millivolt Signals,Resistance Temperature Detectors(RTDs),etc.
Accuracy:±0.1%FS(Full Scale)
Operating Temperature Range:-20°C to+60°C
Storage Temperature Range:-40°C to+85°C
Communication Protocol:Modbus RTU
Features
High-Precision Signal Acquisition:Utilizes a 24-bit,high-resolution ADC to ensure accurate signal acquisition.
Multiple Signal Support:Supports a wide range of industrial signal types to meet the needs of diverse industrial scenarios.
Isolated Design:Each channel is equipped with an independent analog-to-digital converter and signal isolation circuit to prevent signal interference and improve system stability.
Flexible Configuration:Supports independent software settings for input type and range for each channel,allowing users to configure the device to their needs.
Communication Compatibility:Compatible with various industrial communication protocols,including Modbus RTU,for easy integration with other systems.
