描述
ABB IMDSI14是一款数字量输入子模件，属于ABB Symphony Plus I/O HR系列，以下是其详细信息：
基本信息
品牌：ABB
型号：IMDSI14
输入电压：48VDC
输出信号电平：0或5V
通道数量：16路独立输入通道
地址设置方式：通过8位地址拨码开关（S1）进行地址设置，在I/O扩展总线上可设置64个地址（地址范围0到63）。
外观设计
前面板：带有16个LED状态指示灯，分为A组和B组，可直观显示每一路输入信号的状态。
后部：设置有P1、P2、P3板边连接器，分别用于连接电源、总线以及现场信号。
尺寸：宽度约3.8厘米，长度约17.8厘米，高度约31.8厘米。
重量：装运重量约1.5千克。
性能特点
信号转换精准：能够精准地将现场的开关、传感器等设备传来的48VDC数字信号转换为0或5V的标准电平信号，以满足控制系统内部的信号处理要求。
抗干扰能力强：输入电路设计经过优化，具备出色的抗干扰能力，可有效抵御工业环境中常见的电磁干扰、电源波动等干扰源，保障信号传输的准确性与稳定性。
应用领域
制造业：用于自动化生产线设备的状态监测与控制。
能源行业：对发电设备、输电设备的运行状态信号进行采集。
化工行业：实时采集生产过程中的各类报警信号与设备状态信号。
交通运输行业：可用于自动化物流分拣系统、智能仓储系统中设备状态信号的采集等。
The ABB IMDSI14 is a digital input submodule belonging to the ABB Symphony Plus I/O HR series.Here are its detailed specifications:
Basic Information
Brand:ABB
Model:IMDSI14
Input Voltage:48VDC
Output Signal Level:0 or 5V
Number of Channels:16 independent input channels
Address Setting Method:Address setting via an 8-bit address DIP switch(S1),allowing for 64 addresses(range 0 to 63)on the I/O expansion bus.
Appearance Design
Front Panel:Features 16 LED status indicators,divided into groups A and B,clearly displaying the status of each input signal.
Rear Panel:Includes P1,P2,and P3 board-side connectors for connecting power,bus,and field signals,respectively.
Dimensions:Approximately 3.8 cm wide,17.8 cm long,and 31.8 cm high.
Weight:Approximately 1.5 kg for shipment.
Performance Characteristics
Precise Signal Conversion:Accurately converts 48VDC digital signals from field switches,sensors,and other equipment into standard 0V or 5V level signals to meet the signal processing requirements of the control system.
Strong Anti-interference Capability:The optimized input circuit design provides excellent anti-interference capability,effectively resisting common interference sources in industrial environments such as electromagnetic interference and power fluctuations,ensuring the accuracy and stability of signal transmission.
Application Areas
Manufacturing:Used for status monitoring and control of automated production line equipment.
Energy Industry:Acquisition of operating status signals from power generation and transmission equipment.
Chemical Industry:Real-time acquisition of various alarm signals and equipment status signals during the production process.
Transportation Industry:Can be used for acquiring equipment status signals in automated logistics sorting systems and intelligent warehousing systems.
