描述
ABB IMDSM05是ABB Bailey Infi 90系列中的高性能数字I/O模块。以下是其详细介绍：
基本参数
工作电压：24V DC。
输出频率：125kHz（典型应用50kHz）。
输入/输出通道：支持多通道配置，常见为16/32点。
响应时间：输入信号检测延迟<0.1ms，输出响应时间<0.5ms。
通信接口：2个以太网口（支持冗余配置）、RS-232/RS-485串口。
工作温度范围：-20℃至+70℃。
防护等级：IP20。
认证标准：UL认证、CE认证、符合IEC 61131-3标准。
物理特性
尺寸：约3.5cm×31cm×17.5cm。
重量：约0.28kg。
产品特点
灵活配置：IMDSM05的16路数字I/O从站模块的I/O信号分为两组，每组8路（A组和B组）。根据DSM配置，每个组可以配置为输入组或输出组。
高速信号处理：输入信号检测延迟低至0.1ms，输出响应时间仅0.5ms，可满足高速控制需求。
冗余通信设计：支持2个以太网口配置为冗余链路，主链路故障时，系统可在10ms内自动切换至备用链路。
兼容性强：可通过FBP总线适配器兼容Profibus DP、DeviceNet等多种现场总线协议。
可靠耐用：工作温度范围为-20℃至+60℃，存储温度范围为-40℃至+85℃，适应多种工业环境。
应用领域
离散制造业：可用于高速包装机械控制，通过数字输入监测传感器信号，数字输出控制执行机构，提高生产效率。
过程工业：在水处理系统监控中，可构建分布式I/O系统，通过冗余以太网连接中央控制室与远程泵站。
能源行业：适用于风电场变桨控制，通过高速数字输出驱动伺服电机，同时通过数字输入监测限位开关状态。
The ABB IMDSM05 is a high-performance digital I/O module in the ABB Bailey Infi 90 series.The following is a detailed introduction:
Basic Parameters
Operating Voltage:24V DC.
Output Frequency:125kHz(typically 50kHz).
Input/Output Channels:Supports multi-channel configurations,with 16/32 points being common.
Response Time:Input signal detection delay<0.1ms,output response time<0.5ms.
Communication Interfaces:Two Ethernet ports(redundant configuration supported),RS-232/RS-485 serial ports.
Operating Temperature Range:-20°C to+70°C.
Protection Rating:IP20.
Certifications:UL,CE,and compliant with IEC 61131-3.
Physical Characteristics
Dimensions:Approximately 3.5cm×31cm×17.5cm.
Weight:Approximately 0.28kg.Product Features
Flexible Configuration:The IMDSM05’s 16-channel digital I/O slave module’s I/O signals are divided into two groups of 8 channels each(Group A and Group B).Each group can be configured as either an input or output group based on the DSM configuration.
High-SpeedSignal Processing:Input signal detection latency is as low as 0.1ms,and output response time is only 0.5ms,meeting high-speed control requirements.
Redundant Communication Design:Two Ethernet ports can be configured as redundant links.If the primary link fails,the system automatically switches to the backup link within 10ms.
Strong Compatibility:Compatible with various fieldbus protocols such as Profibus DP and DeviceNet via the FBP bus adapter.
Reliable and Durable:With an operating temperature range of-20°C to+60°C and a storage temperature range of-40°C to+85°C,it adapts to various industrial environments.
Applications
Discrete Manufacturing:It can be used for high-speed packaging machinery control,monitoring sensor signals through digital inputs and controlling actuators through digital outputs,improving production efficiency.Process Industries:For water treatment system monitoring,a distributed I/O system can be built,connecting the central control room and remote pumping stations via redundant Ethernet.
Energy Industries:Suitable for wind farm pitch control,high-speed digital outputs drive servo motors while digital inputs monitor limit switch status.
