描述
ABB IMDSO14是ABB Infi 90分布式控制系统（DCS）中的数字从站输出模块。以下是其产品详情：
基本参数
电气参数：工作电压为内部逻辑电源5V DC（±5%），典型电流275mA，最大电流370mA；负载电压支持24VDC或48VDC，每个通道最大负载电流为2A。
输出参数：拥有16个数字输出通道，输出通道可配置为继电器输出、晶闸管输出或晶体管输出。
隔离参数：输入、输出与电源之间具备500V AC隔离电压。
环境参数：工作温度范围为-25°C至+55°C，存储温度范围为-40°C至+70°C，相对湿度为5%-95%无冷凝。
外形尺寸：净深度71.12毫米，净高358.14毫米，净宽271.78毫米。
重量：约0.2kg。
产品特点
多通道数字输出：16个独立输出通道，可同时控制多个现场设备，满足复杂工业场景需求。
灵活电压适配：支持24VDC或48VDC负载电压，可根据所控设备电压要求灵活选择。
模块化便捷设计：结构紧凑，便于安装在控制柜等有限空间内，且易于扩展。
可靠信号隔离：具备500V AC隔离功能，能有效隔离现场电气干扰，确保信号传输稳定准确。
应用领域
能源行业：可用于燃气输送系统控制管道阀门开关，或污水处理厂控制泵机、搅拌器等设备。
化工、制药与食品加工行业：在化工生产中控制反应釜进料阀门、搅拌电机等；在制药行业控制药品生产设备；在食品加工领域控制包装机、灌装机等。
电力和基础设施领域：用于电力系统中变电站设备控制与监测，如高压开关分合闸；在基础设施建设中控制电梯、照明系统、通风系统等。
The ABB IMDSO14 is a digital slave output module for the ABB Infi 90 distributed control system(DCS).The following are product details:
Basic Parameters
Electrical Parameters:Operating voltage is 5V DC(±5%)from the internal logic power supply,with a typical current of 275mA and a maximum current of 370mA.Load voltage supports 24V DC or 48V DC,with a maximum load current of 2A per channel.
Output Parameters:Provides 16 digital output channels,configurable as relay,thyristor,or transistor outputs.
Isolation Parameters:500V AC isolation between inputs,outputs,and the power supply.
Environmental Parameters:Operating temperature range:-25°C to+55°C,storage temperature range:-40°C to+70°C,relative humidity:5%-95%non-condensing.
Dimensions:Net depth 71.12 mm,net height 358.14 mm,net width 271.78 mm.
Weight:Approximately 0.2 kg.
Features
Multi-channel digital output:16 independent output channels enable simultaneous control of multiple field devices,meeting the needs of complex industrial scenarios.
Flexible voltage adaptability:Supports 24VDC or 48VDC load voltages,allowing for flexible selection based on the voltage requirements of the controlled equipment.
Modular and convenient design:Compact structure facilitates installation in limited spaces such as control cabinets and is easily expandable.
Reliable signal isolation:500V AC isolation effectively isolates field electrical interference,ensuring stable and accurate signal transmission.
Applications
Energy industry:Can be used to control pipeline valves in gas transmission systems,or to control pumps,mixers,and other equipment in sewage treatment plants.Chemical,Pharmaceutical,and Food Processing Industries:Controls reactor feed valves and agitator motors in chemical production;controls pharmaceutical production equipment in the pharmaceutical industry;and controls packaging and filling machines in the food processing sector.
Power and Infrastructure:Controls and monitors substation equipment in power systems,such as high-voltage switchgear;and controls elevators,lighting systems,and ventilation systems in infrastructure construction.
