描述
ABB INICT03A是一款用于Infi-net网络与计算机之间的数据传输模块，属于ABB Bailey系列。以下是其产品详情：
基本信息
品牌：ABB
产地：瑞典
产品类型：接口模块
电源要求：5VDC 2A
工作温度：-40℃至70℃
湿度：0至95%非冷凝
尺寸：178x51x330mm
重量：0.6kg
技术参数
内存：512KB ROM，2MB RAM
通信速率：RS-232-C用户可选，最高可达19.2Kbaud；SCSI最高可达4MB/秒
标签容量：30000
功能特点
通信桥梁作用：作为连接ABB Symphony Infi-Net工业网络与计算机的桥梁，实现不同设备、系统和网络间可靠的数据传输与通信，可将Infi-Net网络采集的数据传输至计算机端进行存储、分析和监控。
支持多种通信接口：支持RS-232和RS-485通信，提供灵活的连接选项，满足不同设备的通信需求。
数据传输效率高：SCSI接口数据传输速率最高可达4MB/秒，能实现高效的数据传输，确保工业应用中数据的及时处理。
可靠性高：通过冗余硬件和通信媒体增强了可靠性，在主服务器出现故障时，备份会自动接管，并且广泛使用错误检查和消息确认来确保关键过程数据的准确。
易于安装配置：设计用户友好，易于安装和配置，可通过提供的软件选择通信协议、数据速率和所需的Infi-net网络，方便集成到现有系统中。
应用领域
SCADA系统：用于实现SCADA系统中Infi-net网络与计算机之间的数据交互，确保对工业过程的实时监控和控制。
DCS系统：在DCS系统中作为重要的通信接口，实现各控制节点与计算机之间的数据传输，保障系统的稳定运行。
工厂监测系统：可将工厂内各种设备通过Infi-net网络的数据传输到计算机，便于操作人员实时监测设备运行状态。
数据记录系统：与数据记录系统配合，将Infi-net网络中的数据准确记录到计算机中，为后续的数据分析和处理提供基础。
The ABB INICT03A is a data transmission module for communication between InfiNet networks and computers,belonging to the ABB Bailey series.Here are its product details:
Basic Information
Brand:ABB
Origin:Sweden
Product Type:Interface Module
Power Requirement:5VDC 2A
Operating Temperature:-40°C to 70°C
Humidity:0 to 95%non-condensing
Dimensions:178 x 51 x 330 mm
Weight:0.6 kg
Technical Parameters
Memory:512KB ROM,2MB RAM
Communication Rate:RS-232-C(user selectable,up to 19.2Kbaud);SCSI(up to 4MB/s)
Tag Capacity:30,000
Features
Communication Bridge:Acts as a bridge between the ABB Symphony InfiNet industrial network and computers,enabling reliable data transmission and communication between different devices,systems,and networks.It transmits data collected from the InfiNet network to the computer for storage,analysis,and monitoring.
Multiple Communication Interfaces:Supports RS-232 and RS-485 communication,providing flexible connectivity options to meet the communication needs of various devices.
High Data Transmission Efficiency:The SCSI interface supports data transmission rates of up to 4MB/s,ensuring efficient data transfer and timely processing of data in industrial applications.
High Reliability:Enhanced reliability through redundant hardware and communication media;backup automatically takes over in case of primary server failure;extensive use of error checking and message acknowledgment ensures the accuracy of critical process data.
Easy Installation and Configuration:User-friendly design for easy installation and configuration;communication protocols,data rates,and required InfiNet network can be selected via provided software,facilitating integration into existing systems.
Applications
SCADA Systems:Enables data exchange between InfiNet networks and computers in SCADA systems,ensuring real-time monitoring and control of industrial processes.
DCS Systems:Serves as a critical communication interface in DCS systems,enabling data transmission between control nodes and computers,ensuring stable system operation.
Factory Monitoring Systems:Transmits data from various devices in a factory via the InfiNet network to a computer,allowing operators to monitor device status in real time.Data logging system:This system works in conjunction with the Infi-net network to accurately record data onto a computer,providing a foundation for subsequent data analysis and processing.
