描述
ABB INNIS01是一款网络接口从属模块，属于ABB Bailey INFI 90控制系统的一部分，以下是其详细信息：
硬件参数
工作电压：+5VDC（900mA，额定功率4.50W）；+15VDC（5mA，额定功率0.08W）；-15VDC（200mA，额定功率3.00W）。
内存：随机存取存储器（RAM）为208KB，只读存储器（ROM）为64KB。
通信速率：支持10Mbps或2Mbps。
尺寸：约3.6cm×31.5cm×17.7cm。
重量：约0.42kg。
外观设计
前面板：设有两个锁定螺丝，用于将模块稳固地固定在模块安装单元上，还配备了16个LED指示灯，可直观地显示错误代码以及事件/错误计数。
安装方式：采用单块印刷电路板设计，在标准的INFI 90 OPEN模块安装单元中占据一个插槽。
功能特点
通信功能强大：与INNP11网络处理模块（NPM）共同构成过程控制单元接口，为过程控制单元中的控制模块提供接入INFI-net®通信系统的途径，使节点能够与INFI-net环路上的其他任何节点进行通信。
故障诊断便捷：前面板的16个LED指示灯可帮助运维人员快速定位和排查故障，缩短系统维护时间。
应用领域
工业自动化：可实现自动化设备和系统之间的无缝集成与通信。
楼宇管理：能对楼宇系统进行集中控制和监测。
电力行业：有助于配电网的高效管理和控制。
过程控制：可增强工业过程中控制系统的协调和同步。
智能电网：支持智能电网组件的集成和通信。
The ABB INNIS01 is a network interface slave module part of the ABB Bailey INFI 90 control system.Here are its details:
Hardware Specifications
Operating Voltage:+5VDC(900mA,4.50W rated power);+15VDC(5mA,0.08W rated power);-15VDC(200mA,3.00W rated power).
Memory:208KB RAM,64KB ROM.
Communication Rate:Supports 10Mbps or 2Mbps.
Dimensions:Approx.3.6cm×31.5cm×17.7cm.
Weight:Approx.0.42kg.
Design
Front Panel:Features two locking screws for securely attaching the module to the module mounting unit,and 16 LEDs for visually displaying error codes and event/error counts.
Installation Method:Employs a single printed circuit board design,occupying one slot in the standard INFI 90 OPEN module mounting unit.
Features
Powerful Communication Capabilities:Together with the INNP11 Network Processing Module(NPM),it forms the process control unit interface,providing control modules in the process control unit with a way to access the INFI-net®communication system,enabling nodes to communicate with any other node on the INFI-net loop.
Easy Fault Diagnosis:16 LED indicators on the front panel help maintenance personnel quickly locate and troubleshoot faults,reducing system maintenance time.
Application Areas
Industrial Automation:Enables seamless integration and communication between automated equipment and systems.
Building Management:Enables centralized control and monitoring of building systems.
Power Industry:Facilitates efficient management and control of power distribution networks.
Process Control:Enhances the coordination and synchronization of control systems in industrial processes.
Smart Grid:Supports the integration and communication of smart grid components.
