描述
ABB INNPM22是一款功能强大的网络处理器模块，以下是其产品详情：
基本信息
品牌：ABB
产品型号：INNPM22
产品类型：网络处理器模块
产地：瑞典
尺寸：100mm×60mm×30mm
重量：0.2kg
工作电压：24V DC
认证：CE、RoHS
技术参数
处理器：采用ColdFire MCF5407，主频为160MHz。
内存：8MB DRAM，512KB NVRAM。
通信接口：具备2个10/100/1000Mbps以太网端口，2个RS-232/RS-485串行端口，1个CAN总线接口。
通信速率：支持10/100Mbps以太网通信速率。
工作温度范围：-40℃至+85℃。
功能特点
高速通信：支持高速以太网通信协议，可无缝集成至ABB 800xA、Symphony Plus等DCS系统，通信速率高达100Mbps，能确保关键控制信号无延迟传输。
多协议支持：支持HART、Modbus RTU、OPC UA、MQTT等工业物联网协议，可轻松接入数字孪生与预测性维护平台。
信号处理能力：支持4-20mA（负载≤250Ω）、0-10V（阻抗≥1MΩ）标准工业信号输入，提供隔离后的4-20mA/0-10V信号（可选）以及RS-485 Modbus RTU接口，转换精度为±0.1%FS（25℃），输入-输出-电源间隔离强度为1500V DC。
智能诊断：内置断线检测、超量程报警等故障诊断机制，可实时监测通道状态并通过LED指示灯直观反馈，检测到异常时自动切换至安全模式。
模块化设计：支持带电插拔的DIN导轨安装方式，便于安装和维护，可在不停机状态下更换故障通道。
应用领域
电力行业：可用于变电站自动化，采集变压器油温、断路器分合闸电流等参数，也可用于发电厂控制，如在汽轮机调速系统中实时采集蒸汽压力与转速信号。
化工与石化行业：能用于反应釜控制，监测反应温度、压力及成分信号，还可用于管道监测，通过涡街流量计采集气体流量信号。
冶金行业：可应用于高炉煤气回收，采集煤气压力与温度信号，动态调整引风机转速，也可用于连铸机控制，调节结晶器液位。
水处理行业：可用于污水处理，监测溶解氧浓度与污泥浓度，也可用于海水淡化，采集进水压力与产水电导率信号。
The ABB INNPM22 is a powerful network processor module.Below are its product details:
Basic Information
Brand:ABB
Model:INNPM22
Product Type:Network Processor Module
Origin:Sweden
Dimensions:100mm×60mm×30mm
Weight:0.2kg
Operating Voltage:24V DC
Certifications:CE,RoHS
Technical Parameters
Processor:ColdFire MCF5407,160MHz
Memory:8MB DRAM,512KB NVRAM
Communication Interfaces:Two 10/100/1000Mbps Ethernet ports,two RS-232/RS-485 serial ports,and one CAN bus interface.
Communication Rate:Supports 10/100Mbps Ethernet communication rates.
Operating Temperature Range:-40°C to+85°C
Features
High-SpeedCommunication:Supports high-speed Ethernet communication protocols,enabling seamless integration into DCS systems such as ABB 800xA and Symphony Plus.Communication rates up to 100Mbps ensure delay-free transmission of critical control signals.
Multi-Protocol Support:Supports industrial IoT protocols such as HART,Modbus RTU,OPC UA,and MQTT,enabling easy integration into digital twin and predictive maintenance platforms.
Signal Processing:Supports standard industrial signal inputs such as 4-20mA(load≤250Ω)and 0-10V(impedance≥1MΩ).It also provides isolated 4-20mA/0-10V signals(optional)and an RS-485 Modbus RTU interface.Conversion accuracy is±0.1%FS(25°C),and isolation strength between input,output,and power is 1500V DC.Intelligent Diagnosis:Built-in fault diagnosis mechanisms such as disconnection detection and over-range alarms monitor channel status in real time,providing intuitive feedback through LED indicators.Automatically switches to safe mode when an anomaly is detected.
Modular Design:Supports live-swappable DIN rail mounting for easy installation and maintenance,allowing faulty channels to be replaced without shutting down the system.
Applications:
Power Industry:Suitable for substation automation,collecting parameters such as transformer oil temperature and circuit breaker trip and closing currents.It can also be used for power plant control,such as real-time steam pressure and speed signals in turbine speed control systems.
Chemical and Petrochemical Industry:Suitable for reactor control,monitoring reaction temperature,pressure,and composition signals.It can also be used for pipeline monitoring,collecting gas flow signals through vortex flowmeters.
Metallurgical Industry:Suitable for blast furnace gas recovery,collecting gas pressure and temperature signals to dynamically adjust induced draft fan speed.It can also be used in continuous casting machine control to adjust the mold level.
Water Treatment Industry:Suitable for wastewater treatment,monitoring dissolved oxygen concentration and sludge concentration.It can also be used in seawater desalination,collecting inlet pressure and product water conductivity signals.
