描述
ABB NINT-72C是一款工业自动化领域的通讯模块，以下是其产品详情：
技术规格
通信协议：集成PROFINET、Ethernet/IP、Modbus TCP/IP等工业以太网协议。
输入电压范围：支持三相AC380-480V宽电压输入（±15%）。
采样率：搭载16位ADC采样精度，支持200kHz采样率。
扩展接口：提供10针螺栓端子和25针D-SUB接口，扩展I/O接口集成8路数字量输入（DI）、4路数字量输出（DO）及2路模拟量输入（AI）。
工作温度范围：-25°C至+60°C。
防护等级：IP20。
功能特点
多协议通信：可与西门子S7-1500、罗克韦尔ControlLogix等主流PLC实现设备级数据互联。
宽电压适应：内置2300Vrms绝缘等级过压保护模块，欠压保护阈值可设为320V，能应对复杂电网环境。
高速采样与控制：可捕捉电机电流、电压波形，结合PID控制算法，实现高精度控制。
模块化设计：支持热插拔功能，无需断电即可更换模块，方便安装与维护。
应用领域2
冶金行业：可用于连铸机系统，通过总线同步控制变频器，稳定结晶器振动频率，降低铸坯表面裂纹率。
能源行业：在风力发电机组中，可通过PROFINET协议与主控系统通信，实时调整桨叶角度以优化发电效率，在低温环境下也能稳定运行。
造纸行业：用于高速复卷机，通过模拟量输入接口连接张力传感器，将纸卷张力波动控制在较小范围内，提升生产效率，降低废品率。
The ABB NINT-72C is a communication module for industrial automation.The following are product details:
Technical Specifications
Communication Protocols:Integrated with PROFINET,Ethernet/IP,Modbus TCP/IP,and other industrial Ethernet protocols.
Input Voltage Range:Supports three-phase AC 380-480V wide input voltage(±15%).
Sampling Rate:Equipped with 16-bit ADC sampling accuracy,it supports a 200kHz sampling rate.
Expansion Interface:Provides 10-pin screw terminal and 25-pin D-SUB connectors.The expansion I/O interface integrates 8 digital inputs(DI),4 digital outputs(DO),and 2 analog inputs(AI).
Operating Temperature Range:-25°C to+60°C.
Protection Rating:IP20.
Features
Multi-protocol Communication:Enables device-level data interconnection with mainstream PLCs such as the Siemens S7-1500 and Rockwell ControlLogix.Wide Voltage Adaptability:A built-in 2300Vrms insulation-rated overvoltage protection module and an adjustable undervoltage protection threshold of 320V ensure compatibility with complex power grid environments.
High-SpeedSampling and Control:Captures motor current and voltage waveforms,combining them with a PID control algorithm for high-precision control.
Modular Design:Hot-swappable,modules can be replaced without powering off,facilitating installation and maintenance.
Applications:
Metallurgical Industry:Suitable for continuous casting systems,it synchronizes inverter control via a bus to stabilize mold vibration frequency and reduce surface cracking in the ingot.
Energy Industry:In wind turbines,it communicates with the main control system via PROFINET,enabling real-time blade angle adjustment to optimize power generation efficiency.It also maintains stable operation even in low-temperature environments.
Papermaking Industry:Suitable for high-speed rewinders,it connects to a tension sensor via an analog input interface to minimize paper roll tension fluctuations,improving production efficiency and reducing scrap.
