描述
ABB NINT-72C是一款应用于工业自动化领域的通信板或主电路接口板，以下是其产品详情：
基本信息
品牌：ABB
产地：瑞典
类型：主电路接口板
尺寸：220mm×160mm×60mm
重量：约2kg
工作温度范围：-20℃至+60℃
防护等级：IP20
技术参数
输入电压范围：三相AC380-480V（±15%）
通信协议：支持PROFINET、Ethernet/IP、Modbus TCP等
采样率：200kHz
扩展接口：提供10针螺栓端子和25针D-SUB接口，支持热插拔，扩展I/O接口集成8路数字量输入、4路数字量输出及2路模拟量输入
输出电压：DC 24V
产品特点
多协议兼容性：可与西门子S7-1500、罗克韦尔ControlLogix等主流PLC实现设备级数据互联。
宽电压适应性：支持三相AC380-480V宽电压输入（±15%），内置2300Vrms绝缘等级过压保护模块。
高速采样与实时控制：搭载16位ADC采样精度，支持200kHz采样率，可捕捉电机电流、电压波形。
隔离保护：提供驱动与控制系统之间的隔离，提高系统的安全性。
应用领域
广泛应用于工业自动化、电力系统、建筑、交通运输、石油和天然气、矿山、冶金、化工、食品和饮料等领域。
The ABB NINT-72C is a communication board or main circuit interface board for industrial automation.The following are product details:
Basic Information
Brand:ABB
Origin:Sweden
Type:Main Circuit Interface Board
Dimensions:220mm×160mm×60mm
Weight:Approximately 2kg
Operating Temperature Range:-20°C to+60°C
Protection Rating:IP20
Technical Parameters
Input Voltage Range:Three-phase AC 380-480V(±15%)
Communication Protocols:Supports PROFINET,Ethernet/IP,Modbus TCP,etc.
Sampling Rate:200kHz
Expansion Interface:Provides 10-pin screw terminal and 25-pin D-SUB connectors,both hot-swappable.The expansion I/O interface integrates 8 digital inputs,4 digital outputs,and 2 analog inputs.
Output Voltage:DC 24V
Product Features
Multi-protocol Compatibility:Compatible with mainstream protocols such as Siemens S7-1500 and Rockwell ControlLogix PLC enables device-level data interconnection.
Wide Voltage Adaptability:Supports three-phase AC 380-480V wide input voltage(±15%)and features a built-in 2300Vrms insulation overvoltage protection module.
High-SpeedSampling and Real-Time Control:Equipped with 16-bit ADC sampling accuracy and supporting a 200kHz sampling rate,it can capture motor current and voltage waveforms.
Isolation Protection:Provides isolation between the drive and control systems,enhancing system safety.
Application Areas:Widely used in industrial automation,power systems,construction,transportation,oil and gas,mining,metallurgy,chemicals,food and beverages,and other fields.
