描述
ABB NINT-72C是一款应用于工业自动化领域的控制卡，以下是其产品详情：
基本信息
品牌：ABB
型号：NINT-72C
类型：控制卡
尺寸：150mm×100mm×30mm
重量：0.3kg
技术参数
工作电压：DC 24V
输入电压范围：三相AC 380-480V（±15%）
通信接口：RS-485、Modbus
协议兼容性：集成PROFINET、Ethernet/IP、Modbus TCP/IP等工业以太网协议
处理速度：20MHz
内存容量：512KB RAM，1MB Flash
采样率：200kHz（16位ADC）
工作温度范围：-20°C至+60°C
防护等级：IP20
产品特点
高性能处理：搭载32位ARM Cortex-M7内核，主频200MHz，支持浮点运算，可实时处理复杂控制算法，如矢量控制、直接转矩控制等。
多协议通信：支持多种工业以太网协议，可与西门子S7-1500、罗克韦尔ControlLogix等主流PLC实现设备级数据互联，方便系统集成。
宽电压适应：支持三相AC 380-480V宽电压输入，内置2300Vrms绝缘等级过压保护模块，欠压保护阈值可设为320V，能有效应对复杂电网环境。
高速采样与控制：搭载16位ADC采样精度，支持200kHz采样率，可捕捉电机电流、电压波形，实现高速采样与实时控制。
模块化设计：提供10针螺栓端子和25针D-SUB接口，支持热插拔功能，扩展I/O接口集成8路数字量输入、4路数字量输出及2路模拟量输入，可连接多种外围设备。
应用领域
广泛应用于工业自动化、电力系统、建筑、交通运输、石油和天然气、矿山、冶金、化工、食品和饮料等领域，可用于风机、水泵、压缩机等通用传动应用，以及电梯、起重机等物料搬运应用和纺织、印刷、橡胶塑料等加工机械应用。
The ABB NINT-72C is a control card used in industrial automation.Below are its product details:Basic Information Brand:ABB Model:NINT-72C Type:Control Card Dimensions:150mm×100mm×30mm Weight:0.3kg Technical Specifications Operating Voltage:DC 24V Input Voltage Range:Three-phase AC 380-480V(±15%)Communication Interface:RS-485,Modbus Protocol Compatibility:Integrated PROFINET,Ethernet/IP,Modbus TCP/IP and other industrial Ethernet protocols Processing Speed:20MHz Memory Capacity:512KB RAM,1MB Flash Sampling Rate:200kHz(16-bit ADC)Operating Temperature Range:-20°C to+60°C Protection Rating:IP20 Product Features High-Performance Processing:Equipped with a 32-bit ARM Cortex-M7 core,high clock speed…200MHz,supports floating-point operations,enabling real-time processing of complex control algorithms such as vector control and direct torque control.
Multi-protocol communication:Supports multiple industrial Ethernet protocols,allowing for device-level data interconnection with mainstream PLCs such as Siemens S7-1500 and Rockwell ControlLogix,facilitating system integration.
Wide voltage adaptability:Supports three-phase AC 380-480V wide voltage input,with a built-in 2300Vrms insulation class overvoltage protection module and an undervoltage protection threshold set to 320V,effectively handling complex power grid environments.
High-speed sampling and control:Equipped with a 16-bit ADC sampling accuracy,supports a 200kHz sampling rate,capturing motor current and voltage waveforms for high-speed sampling and real-time control.
Modular Design:Offers a 10-pin screw terminal and a 25-pin D-SUB interface,supporting hot-swapping.The expanded I/O interface integrates 8 digital inputs,4 digital outputs,and 2 analog inputs,allowing connection to various peripheral devices.
Application Areas:Widely used in industrial automation,power systems,construction,transportation,oil and gas,mining,metallurgy,chemical,food and beverage,and other fields.It can be used in general drive applications such as fans,pumps,and compressors,as well as material handling applications such as elevators and cranes,and processing machinery applications in textiles,printing,rubber and plastics,etc.
