描述
ABB NISA-03是一款DDCS/ISA适配器，主要用于连接个人桌面计算机与ABB ACS 600系列驱动器。以下是其产品详情：
基本信息
品牌：ABB
型号：NISA-03
产品类型：接口板
产地：瑞典
尺寸：约2.5cm×12.7cm×17.8cm
重量：约0.1kg
技术参数
插槽类型：占用计算机主板上的标准16位ISA插槽。
默认I/O地址：280H
光学通道：有两个DDCS协议光学通道，一个配备5兆波特光学组件，另一个配备10兆波特光学组件。
连接线缆：与ACx 600的NAMC（应用和电机控制板）通过光纤电缆连接，RXD CH0通道使用POF（塑料光纤），长度≤15m，用于NAMC-03/04/11（带NDCO-03通信选件）；RXD CH1通道使用POF，长度≤30m，用于NAMC-11（带NDCO-01或NDCO-02通信选件）/21，也可使用HCS（硬包层石英光纤），长度≤200m，用于NDBU-85/95。
产品功能：可使用DriveWare PC软件（如DriveWindow）来控制ABB ACS 600系列驱动器，信号可通过NDBU系列分支单元分配到多个驱动器。
The ABB NISA-03 is a DDCS/ISA adapter primarily used to connect personal desktop computers to ABB ACS 600 series drives.The following are product details:
Basic Information
Brand:ABB
Model:NISA-03
Product Type:Interface Board
Origin:Sweden
Dimensions:Approximately 2.5cm×12.7cm×17.8cm
Weight:Approximately 0.1kg
Technical Parameters
Slot Type:Occupies a standard 16-bit ISA slot on a computer motherboard.
Default I/O Address:280H
Optical Channels:Provides two DDCS protocol optical channels,one equipped with 5 Mbps optical components and the other with 10 Mbps optical components.
Connecting Cable:Connects to the ACx 600’s NAMC(Application and Motor Control Board)via fiber optic cable.RXD CH0 uses POF(Plastic Optical Fiber),length≤15m,for NAMC-03/04/11(with NDCO-03 communication option);RXD CH1 uses POF,length≤30m,for NAMC-11(with NDCO-01 or NDCO-02 communication option)/21.HCS(Hard Clad Silica Fiber),length≤200m,for NDBU-85/95 is also acceptable.
Product Features:DriveWare PC software(such as DriveWindow)can be used to control ABB ACS 600 series drives,and signals can be distributed to multiple drives using the NDBU series branching unit.
