描述
ABB NTMP01是一款多功能处理器终端单元，主要用于ABB Bailey Infi 90系统。以下是其产品详情：
基本信息
品牌：ABB
型号：NTMP01
产品类型：多功能处理器终端单元
尺寸：213.36mm×233.68mm×73.66mm
重量：约0.3kg
电源电压：24V DC
功率消耗：≤3W
工作温度范围：-20°C至+60°C
存储温度范围：-40°C至+85°C
防护等级：IP20
技术参数
通信接口：提供两个RS-232-C串行端口或一个RS-232-C端口和一个RS-485端口。
通信协议：支持Modbus RTU协议，也可通过InfiNet网络进行系统级数据交互。
输入/输出通道：支持8路数字输入（24V DC）和4路数字输出（24V DC，最大负载1A）。
编程语言：支持梯形图、功能块图等编程语言。
内存：内置64KB RAM用于临时数据处理，256KB EEPROM用于程序和参数存储。
功能特点
多功能集成：集成了数据处理、通信交互和控制逻辑执行等多种功能，可实现中小型系统的核心控制任务，无需额外模块，简化了系统架构。
兼容性强：可与ABB Bailey Infi 90系统中的多种设备配合使用，如BRC、MFP、IET、ICT、NK TU等。
可靠性高：具有高MTBF（平均无故障时间）rating，能在恶劣的工业环境中稳定运行，确保系统的可靠性和稳定性。
诊断功能：具备先进的诊断工具，可进行主动维护，减少停机时间，提高系统的整体正常运行时间。
The ABB NTMP01 is a multi-function processor termination unit primarily used in ABB Bailey Infi 90 systems.Below are its product details:
Basic Information
Brand:ABB
Model:NTMP01
Product Type:Multi-function Processor Termination Unit
Dimensions:213.36mm×233.68mm×73.66mm
Weight:Approx.0.3kg
Power Supply:24V DC
Power Consumption:≤3W
Operating Temperature Range:-20°C to+60°C
Storage Temperature Range:-40°C to+85°C
Protection Rating:IP20
Technical Specifications
Communication Interfaces:Provides two RS-232-C serial ports or one RS-232-C port and one RS-485 port.
Communication Protocols:Supports Modbus RTU protocol and can also perform system-level data exchange via InfiNet network.
Input/Output Channels:Supports 8 digital inputs(24V DC)and 4 digital outputs(24V DC,maximum load 1A).
Programming Languages:Supports ladder diagram,function block diagram,and other programming languages.
Memory:Built-in 64KB RAM for temporary data processing and 256KB EEPROM for program and parameter storage.
Features
Multi-functional Integration:Integrates multiple functions such as data processing,communication interaction,and control logic execution,enabling core control tasks in small to medium-sized systems without the need for additional modules,simplifying the system architecture.
Strong Compatibility:Compatible with various devices in the ABB Bailey Infi 90 system,such as BRC,MFP,IET,ICT,NK TU,etc.
High Reliability:Features a high MTBF(Mean Time Between Failures)rating,ensuring stable operation in harsh industrial environments and guaranteeing system reliability and stability.
Diagnostic Functions:Equipped with advanced diagnostic tools for proactive maintenance,reducing downtime and improving overall system uptime.
